Project #15: Environment – Soil Moisture Sensor – Mk20
——
#DonLucElectronics #DonLuc #Arduino #ASM #Project #Patreon #Electronics #Microcontrollers #IoT #Fritzing #Programming #Consultant
——
——
——
——
Soil Moisture Sensor
Soil moisture is the critical parameter in agriculture. If there is a shortage or overabundance of water, plants may die. At the same time, this data depends on many external factors, primarily weather conditions and climate changes. That is why it is so vital to understand the most effective methods for analyzing soil moisture content.
This term refers to the entire quantity of water in the ground’s pores or on its surface. The moisture content of soil depends on such factors as weather, type of land, and plants. The parameter is vital in monitoring soil moisture activities, predicting natural disasters, managing water supply, etc. This data may signal a future flood or water deficit ahead of other indicators.
DL2411Mk03
1 x SparkFun RedBoard Qwiic
1 x Gravity: Analog Soil Moisture Sensor
2 x LED
1 x ProtoScrewShield
1 x USB Battery Pack
1 x USB Micro-B Cable
SparkFun RedBoard Qwiic
ASM – A0
LEDP- 13
LEDG- 12
VIN – +5V
GND – GND
DL2411Mk03p
DL2411Mk03p.ino
/****** Don Luc Electronics © ****** Software Version Information Project #15: Environment – Soil Moisture Sensor – Mk20 15-20 DL2411Mk03p.ino DL2411Mk03 1 x SparkFun RedBoard Qwiic 1 x Gravity: Analog Soil Moisture Sensor 2 x LED 1 x ProtoScrewShield 1 x USB Battery Pack 1 x USB Micro-B Cable */ // Include the Library Code // Gravity: Analog Soil Moisture Sensor int iSoilMoisture = A0; int iSoilMoistureVal = 0; int zz = 0; // Change Your Threshold Here int Threshold = 300; // LED ProtoScrewShield Yellow int iLEDProto = 13; // LED Green int iLEDGreen = 12; // Software Version Information String sver = "15-20"; void loop() { // Gravity: Analog Soil Moisture Sensor isSoilMoisture(); // Delay 1 Second delay( 1000 ); }
getSoilMoisture.ino
// Gravity: Analog Soil Moisture Sensor // Soil Moisture void isSoilMoisture(){ // Connect Soil Moisture Sensor to Analog 0 zz = analogRead( iSoilMoisture ); // iSoilMoistureVal => 0~900 Soil Moisture iSoilMoistureVal = map( zz, 0, 715, 0, 900); // Serial Serial.print("Moisture Sensor Value: "); // Threshold if (iSoilMoistureVal > Threshold) { // 300~900 - Humid Soil // LEDProto digitalWrite(iLEDProto, LOW); // Serial Serial.print( "Humid Soil " ); Serial.println( iSoilMoistureVal ); // LEDGreen digitalWrite(iLEDGreen, HIGH); } else { // 0-300 Dry Soil // LEDGreen digitalWrite(iLEDGreen, LOW); // Serial Serial.print( "Dry Soil " ); Serial.println( iSoilMoistureVal ); // LEDProto digitalWrite(iLEDProto, HIGH); } }
setup.ino
// Setup void setup() { // Delay delay(100); // Serial Serial.begin(57600); // Initialize the LED iLEDProto pinMode(iLEDProto, OUTPUT); // Initialize the LED iLEDGreen pinMode(iLEDGreen, OUTPUT); // Delay 1 Second delay( 1000 ); }
——
People can contact us: https://www.donluc.com/?page_id=1927
Electronics, IoT, Teacher, Instructor, R&D and Consulting
- Programming Language
- Single-Board Microcontrollers (PIC, Arduino, Raspberry Pi, Arm, Silicon Labs, Espressif, Etc…)
- IoT
- Wireless (Radio Frequency, Bluetooth, WiFi, Etc…)
- Robotics
- Automation
- Camera and Video Capture Receiver Stationary, Wheel/Tank and Underwater Vehicle
- Unmanned Vehicles Terrestrial and Marine
- Machine Learning
- Artificial Intelligence (AI)
- RTOS
- Sensors, eHealth Sensors, Biosensor, and Biometric
- Research & Development (R & D)
- Consulting
Follow Us
Luc Paquin – Curriculum Vitae – 2024
https://www.donluc.com/luc/
Web: https://www.donluc.com/
Facebook: https://www.facebook.com/neosteam.labs.9/
YouTube: https://www.youtube.com/@thesass2063
Twitter: https://twitter.com/labs_steam
Pinterest: https://www.pinterest.com/NeoSteamLabs/
Instagram: https://www.instagram.com/neosteamlabs/
Patreon: https://patreon.com/DonLucElectronics59
DFRobot: https://learn.dfrobot.com/user-10186.html
Hackster.io: https://www.hackster.io/neosteam-labs
Elecrow: https://www.elecrow.com/share/sharepj/center/no/760816d385ebb1edc0732fd873bfbf13
TikTok: https://www.tiktok.com/@luc.paquin8
Twitch: https://www.twitch.tv/lucpaquin
LinkedIn: https://www.linkedin.com/in/jlucpaquin/
Don Luc
Patreon: Beginner
——
#DonLucElectronics #DonLuc #Arduino #Project #Patreon #Electronics #Microcontrollers #IoT #Fritzing #Programming #Consultant
——
——
——
——
Patreon: Beginner
Beginner: These beginner-friendly microcontrollers is Arduino Uno are easy to use and program with just a computer or laptop, a USB cable, and some open-source software.
What is Arduino?
Arduino board designs use a variety of microprocessors and controllers. The boards are equipped with sets of digital and analog input/output (I/O) pins that may be interfaced to various expansion boards “Shields” or breadboards and other circuits. The boards feature serial communications interfaces, including Universal Serial Bus (USB) on some models, which are also used for loading programs. Arduino boards are able to read inputs, light on a sensor, a finger on a button, or a Twitter message, and turn it into an output, activating a motor, turning on an LED, publishing something online. You can tell your board what to do by sending a set of instructions to the microcontroller on the board. The microcontrollers can be programmed using the C and C++ programming languages, using a standard API which is also known as the Arduino Programming Language, and the Arduino Software (IDE).
Arduino Software (IDE)
A minimal Arduino C/C++ program consists of only two functions:
setup(): This function is called once when a sketch starts after power-up or reset. It is used to initialize variables, input and output pin modes, and other libraries needed in the sketch.
loop(): After setup() function exits, the loop() function is executed repeatedly in the main program. It controls the board until the board is powered off or is reset. It is analogous to the function while.
DL2412Mk01
1 x SparkFun RedBoard Qwiic
1 x Potentiometer 10K Ohm
1 x ProtoScrewShield
2 x LED
1 x USB Micro-B Cable
SparkFun RedBoard Qwiic
POT – A0
LEDP – 13
LEDG – 12
VIN – +5V
GND – GND
——
DL2412Mk01ppp
DL2412Mk01ppp.ino
/****** Don Luc Electronics © ******/ int iPot = A0; int iPotVal = 0; int Threshold = 500; int iLEDProto = 13; int iLEDGreen = 12; String sver = "Beginner"; void setup() { delay(100); Serial.begin(57600); pinMode(iLEDProto, OUTPUT); pinMode(iLEDGreen, OUTPUT); delay( 100 ); } void loop() { iPotVal = analogRead( iPot ); Serial.print("Potentiometer: "); if (iPotVal > Threshold) { digitalWrite(iLEDProto, LOW); Serial.print( "LED Green " ); Serial.println( iPotVal ); digitalWrite(iLEDGreen, HIGH); } else { digitalWrite(iLEDGreen, LOW); Serial.print( "LED Proto " ); Serial.println( iPotVal ); digitalWrite(iLEDProto, HIGH); } delay( 100 ); }
——
DL2412Mk01pp
DL2412Mk01pp.ino
/****** Don Luc Electronics © ****** Software Version Information Patreon: Beginner Beginner DL2412Mk01pp.ino DL2412Mk01 1 x SparkFun RedBoard Qwiic 1 x Potentiometer 1 x ProtoScrewShield 2 x LED 1 x USB Micro-B Cable */ // Include the Library Code // Potentiometer int iPot = A0; int iPotVal = 0; // Change Your Threshold Here int Threshold = 500; // LED ProtoScrewShield Yellow int iLEDProto = 13; // LED Green int iLEDGreen = 12; // Software Version Information String sver = "Beginner"; // Setup void setup() { // Delay delay(100); // Serial Serial.begin(57600); // Initialize the LED iLEDProto pinMode(iLEDProto, OUTPUT); // Initialize the LED iLEDGreen pinMode(iLEDGreen, OUTPUT); // Delay 0.1 Second delay( 100 ); } // Loop void loop() { // Potentiometer // Connect Potentiometer to Analog 0 iPotVal = analogRead( iPot ); // Serial Serial.print("Potentiometer: "); // Threshold if (iPotVal > Threshold) { // LEDProto digitalWrite(iLEDProto, LOW); // Serial Serial.print( "LED Green " ); Serial.println( iPotVal ); // LEDGreen digitalWrite(iLEDGreen, HIGH); } else { // LEDGreen digitalWrite(iLEDGreen, LOW); // Serial Serial.print( "LED Proto " ); Serial.println( iPotVal ); // LEDProto digitalWrite(iLEDProto, HIGH); } // Delay 0.1 Second delay( 100 ); }
——
DL2412Mk01p
DL2412Mk01p.ino
loop()
getPotentiometer.ino
Attaining => get
Combining Form => is
setup.ino
setup()
DL2412Mk01p
DL2411Mk03p.ino
/****** Don Luc Electronics © ****** Software Version Information Patreon: Beginner Beginner DL2412Mk01p.ino DL2412Mk01 1 x SparkFun RedBoard Qwiic 1 x Potentiometer 1 x ProtoScrewShield 2 x LED 1 x USB Micro-B Cable */ // Include the Library Code // Potentiometer int iPot = A0; int iPotVal = 0; // Change Your Threshold Here int Threshold = 500; // LED ProtoScrewShield Yellow int iLEDProto = 13; // LED Green int iLEDGreen = 12; // Software Version Information String sver = "Beginner"; void loop() { // Potentiometer isPotentiometer(); // Delay 0.1 Second delay( 100 ); }
getPotentiometer.ino
// Potentiometer // Potentiometer void isPotentiometer(){ // Connect Potentiometer to Analog 0 iPotVal = analogRead( iPot ); // Serial Serial.print("Potentiometer: "); // Threshold if (iPotVal > Threshold) { // LEDProto digitalWrite(iLEDProto, LOW); // Serial Serial.print( "LED Green " ); Serial.println( iPotVal ); // LEDGreen digitalWrite(iLEDGreen, HIGH); } else { // LEDGreen digitalWrite(iLEDGreen, LOW); // Serial Serial.print( "LED Proto " ); Serial.println( iPotVal ); // LEDProto digitalWrite(iLEDProto, HIGH); } }
setup.ino
// Setup void setup() { // Delay delay(100); // Serial Serial.begin(57600); // Initialize the LED iLEDProto pinMode(iLEDProto, OUTPUT); // Initialize the LED iLEDGreen pinMode(iLEDGreen, OUTPUT); // Delay 0.1 Second delay( 100 ); }
——
People can contact us: https://www.donluc.com/?page_id=1927
Electronics, IoT, Teacher, Instructor, R&D and Consulting
- Programming Language
- Single-Board Microcontrollers (PIC, Arduino, Raspberry Pi, Arm, Silicon Labs, Espressif, Etc…)
- IoT
- Wireless (Radio Frequency, Bluetooth, WiFi, Etc…)
- Robotics
- Automation
- Camera and Video Capture Receiver Stationary, Wheel/Tank and Underwater Vehicle
- Unmanned Vehicles Terrestrial and Marine
- Machine Learning
- Artificial Intelligence (AI)
- RTOS
- Sensors, eHealth Sensors, Biosensor, and Biometric
- Research & Development (R & D)
- Consulting
Follow Us
Luc Paquin – Curriculum Vitae – 2024
https://www.donluc.com/luc/
Web: https://www.donluc.com/
Facebook: https://www.facebook.com/neosteam.labs.9/
YouTube: https://www.youtube.com/@thesass2063
Twitter: https://twitter.com/labs_steam
Pinterest: https://www.pinterest.com/NeoSteamLabs/
Instagram: https://www.instagram.com/neosteamlabs/
Patreon: https://patreon.com/DonLucElectronics59
DFRobot: https://learn.dfrobot.com/user-10186.html
Hackster.io: https://www.hackster.io/neosteam-labs
Elecrow: https://www.elecrow.com/share/sharepj/center/no/760816d385ebb1edc0732fd873bfbf13
TikTok: https://www.tiktok.com/@luc.paquin8
Twitch: https://www.twitch.tv/lucpaquin
LinkedIn: https://www.linkedin.com/in/jlucpaquin/
Don Luc
Project #30 – UNIHIKER – MEMS – Mk07
——
#DonLucElectronics #DonLuc #UNIHIKER #CH4 #VOC #Display #IoT #Project #Debian #Python #Thonny #DFRobot #Fritzing #Programming #Electronics #Microcontrollers #Consultant
——
——
——
——
MEMS
MEMS (Micro-Electromechanical Systems) is the technology of microscopic devices incorporating both electronic and moving parts. MEMS are made up of components between 1 and 100 micrometres in size, and MEMS devices generally range in size from 20 micrometres to a millimetre, although components arranged in arrayscan be more than 1000 mm2. They usually consist of a central unit that processes data, an integrated circuit chip such as microprocessor, and several components that interact with the surroundings, such as microsensors.
DL2410Mk01
1 x UNIHIKER
1 x Fermion: MEMS VOC Gas Detection Sensor
1 x Fermion: MEMS Methane CH4 Gas Detection Sensor
1 x USB Battery Pack
1 x USB 3.1 Cable A to C
UNIHIKER
ADC1 – 21
ADC2 – 22
VIN – +5V
GND – GND
DL2410Mk01p
DL2410Mk01p.py
****** Don Luc Electronics © ****** Software Version Information Project #30 - UNIHIKER - MEMS - Mk07 30-07 DL2410Mk01.py DL2410Mk01 1 x UNIHIKER 1 x Fermion: MEMS VOC Gas Detection Sensor 1 x Fermion: MEMS Methane CH4 Gas Detection Sensor 1 x USB Battery Pack 1 x USB 3.1 Cable A to C -*- coding: utf-8 -*- """ # Import the unihiker library from unihiker import GUI # Import the time library import time # Import the Board module from the pinpong.board package from pinpong.board import Board # Import all modules from the pinpong.extension.unihiker package from pinpong.extension.unihiker import * # Initialize the board by selecting the board type and port number; # if not specified, the program will automatically detect it Board().begin() # Initialize pin 21 as analog input mode # Fermion: MEMS Methane CH4 Gas Detection Sensor adc0 = Pin(Pin.P21, Pin.ANALOG) # Initialize pin 22 as analog input mode # Fermion: MEMS VOC Gas Detection Sensor adc1 = Pin(Pin.P22, Pin.ANALOG) # Instantiate the GUI class and create a gui object gui = GUI() # Display the initial background image 'DL2410Mk01p' img = gui.draw_image(x=0, y=0, w=240, h=320, image='DL2410Mk01p.png') # Fermion: MEMS Methane CH4 Gas Detection Sensor # Display the initial Fermion: MEMS Methane CH4 Gas Detection Sensor valueCH4 valueCH4 = gui.draw_text(x=30, y=151, text='0', font_size=18) # MEMS VOC # Display the initial Fermion: MEMS VOC Gas Detection Sensor valueVOC valueVOC = gui.draw_text(x=30, y=221, text='0', font_size=18) while True: # Fermion: MEMS Methane CH4 Gas Detection Sensor # Read analog value CH4Sensor = adc0.read_analog() valueCH4.config(text=CH4Sensor) # Fermion: MEMS VOC Gas Detection Sensor # Read analog value VOCSensor = adc1.read_analog() valueVOC.config(text=VOCSensor) # Delay for 1 second to keep the screen content displayed for a longer time time.sleep(1)
——
People can contact us: https://www.donluc.com/?page_id=1927
Electronics, IoT, Teacher, Instructor, R&D and Consulting
- Programming Language
- Single-Board Microcontrollers (PIC, Arduino, Raspberry Pi, Arm, Silicon Labs, Espressif, Etc…)
- IoT
- Wireless (Radio Frequency, Bluetooth, WiFi, Etc…)
- Robotics
- Automation
- Camera and Video Capture Receiver Stationary, Wheel/Tank and Underwater Vehicle
- Unmanned Vehicles Terrestrial and Marine
- Machine Learning
- Artificial Intelligence (AI)
- RTOS
- Sensors, eHealth Sensors, Biosensor, and Biometric
- Research & Development (R & D)
- Consulting
Follow Us
Luc Paquin – Curriculum Vitae – 2024
https://www.donluc.com/luc/
Web: https://www.donluc.com/
Facebook: https://www.facebook.com/neosteam.labs.9/
YouTube: https://www.youtube.com/@thesass2063
Twitter: https://twitter.com/labs_steam
Pinterest: https://www.pinterest.com/NeoSteamLabs/
Instagram: https://www.instagram.com/neosteamlabs/
DFRobot Luc.Paquin: https://edu.dfrobot.com/dashboard/makelogs
Hackster.io: https://www.hackster.io/neosteam-labs
ELECROW: https://www.elecrow.com/share/sharepj/center/no/760816d385ebb1edc0732fd873bfbf13
TikTok: www.tiktok.com/@luc.paquin8
LinkedIn: https://www.linkedin.com/in/jlucpaquin/
Don Luc
Project #29 – DFRobot – RTC – Mk31
——
#DonLucElectronics #DonLuc #DFRobot #RTC #SD #ASM #SHTC3 #FireBeetle2ESP32C6 #Display #EEPROM #ESP32 #IoT #SparkFun #Adafruit #Arduino #Project #Fritzing #Programming #Electronics #Microcontrollers #Consultant
——
——
——
——
Real-Time Clock
A Real-Time Clock (RTC) is an electronic device, most often in the form of an integrated circuit, that measures the passage of time. Although the term often refers to the devices in personal computers, servers and embedded systems, RTCs are present in almost any electronic device which needs to keep accurate time of day.
Although keeping time can be done without an RTC, using one has benefits:
- Reliably maintains and provides current time through disruptive system states such as hangs, sleep, reboots, or if given sufficient backup power, full shutdown and hardware reassembly, without the need to have its time set again.
- Low power consumption, important when running from alternate power.
- Frees the main system for time-critical tasks.
- Sometimes more accurate than other methods.
DL2409Mk08
1 x FireBeetle 2 ESP32-C6
1 x Adalogger FeatherWing – RTC + SD
1 x CR1220 3 Volt Lithium Coin Cell Battery
1 x Fermion: SHTC3 Temperature & Humidity Sensor
1 x Fermion: 2.0″ 320×240 IPS TFT LCD
1 x GDL Line 10 CM
1 x Gravity: Analog Soil Moisture Sensor
1 x 3 AAA Battery Holder with On/Off Switch and 2-Pin JST
3 x AAA Battery
1 x SparkFun Solderable Breadboard – Large
1 x USB 3.1 Cable A to C
FireBeetle 2 ESP32-C6
SCL – 20
SDA – 19
ASM – A1
LED – 15
DC – D2
CS – D6
RST – D3
VIN – +3.3V
GND – GND
DL2409Mk08p
DL2409Mk08p.ino
/****** Don Luc Electronics © ****** Software Version Information Project #29 - DFRobot - RTC - Mk31 29-31 DL2409Mk08p.ino DL2409Mk08 1 x FireBeetle 2 ESP32-C6 1 x Adalogger FeatherWing - RTC + SD 1 x CR1220 3 Volt Lithium Coin Cell Battery 1 x Fermion: SHTC3 Temperature & Humidity Sensor 1 x Fermion: 2.0" 320x240 IPS TFT LCD 1 x GDL Line 10 CM 1 x Gravity: Analog Soil Moisture Sensor 1 x 3 AAA Battery Holder with On/Off Switch and 2-Pin JST 3 x AAA Battery 1 x SparkFun Solderable Breadboard - Large 1 x USB 3.1 Cable A to C */ // Include the Library Code // EEPROM Library to Read and Write EEPROM // with Unique ID for Unit #include "EEPROM.h" // Arduino #include <Arduino.h> // Wire #include <Wire.h> // DFRobot Display GDL API #include <DFRobot_GDL.h> // Fermion: SHTC3 Temperature & Humidity Sensor #include"DFRobot_SHTC3.h" // Date and Time Functions PCF8523 RTC #include <RTClib.h> // Date and Time PCF8523 RTC RTC_PCF8523 rtc; String dateRTC = ""; String timeRTC = ""; // Fermion: SHTC3 Temperature & Humidity Sensor DFRobot_SHTC3 SHTC3; uint32_t id = 0; float temperature; float humidity; // Defined ESP32 #define TFT_DC D2 #define TFT_CS D6 #define TFT_RST D3 /*dc=*/ /*cs=*/ /*rst=*/ // DFRobot Display 240x320 DFRobot_ST7789_240x320_HW_SPI screen(TFT_DC, TFT_CS, TFT_RST); // Gravity: Analog Soil Moisture Sensor int iSoilMoisture = A1; int iSoilMoistureVal = 0; int zz = 0; // Change Your Threshold Here int Threshold = 300; String SM = ""; // LED Green int iLEDGreen = 15; // EEPROM Unique ID Information #define EEPROM_SIZE 64 String uid = ""; // Software Version Information String sver = "29-31"; void loop() { // Date and Time PCF8523 RTC isRTC(); // SHTC3 Temperature and Humidity Sensor isSHTC3(); // Gravity: Analog Soil Moisture Sensor isSoilMoisture(); // DFRobot Display 240x320 - ASM - Temperature and Humidity - Date and Time isDisplayTH(); // Delay 5 Second delay( 5000 ); }
getDisplay.ino
// DFRobot Display 240x320 // DFRobot Display 240x320 - UID void isDisplayUID() { // DFRobot Display 240x320 // Text Display // Text Wrap screen.setTextWrap(false); // Rotation screen.setRotation(3); // Fill Screen => black screen.fillScreen(0x0000); // Text Color => white screen.setTextColor(0xffff); // Font => Free Mono 9pt screen.setFont(&FreeMono9pt7b); // TextSize => 1.5 screen.setTextSize(1.5); // DFRobot Display screen.setCursor(0, 30); screen.println("DFRobot Display"); // Don Luc Electronics screen.setCursor(0, 60); screen.println("Don Luc Electronics"); // Version screen.setCursor(0, 90); screen.println("Version"); screen.setCursor(0, 120); screen.println( sver ); // EEPROM screen.setCursor(0, 150); screen.println("EEPROM"); screen.setCursor(0, 180); screen.println( uid ); } // DFRobot Display 240x320 - ASM - Temperature and Humidity void isDisplayTH() { // DFRobot Display 240x320 // Text Display // Text Wrap screen.setTextWrap(false); // Rotation screen.setRotation(3); // Fill Screen => black screen.fillScreen(0x0000); // Text Color => white screen.setTextColor(0xffff); // Font => Free Mono 9pt screen.setFont(&FreeMono9pt7b); // TextSize => 1.5 screen.setTextSize(1.5); // Soil Moisture Sensor screen.setCursor(0, 30); screen.println("Soil Moisture Sensor"); // Date and Time screen.setCursor(0, 60); screen.println( dateRTC + " - " + timeRTC ); // Gravity: Analog Soil Moisture Sensor screen.setCursor(0, 90); screen.println( "ASM: " ); screen.setCursor(60, 90); screen.println( iSoilMoistureVal ); screen.setCursor(0, 120); screen.println( SM ); // SHTC3 Temperature screen.setCursor(0, 150); screen.println( "Tem: " ); screen.setCursor(60, 150); screen.println( temperature ); screen.setCursor(120, 150); screen.println( "C" ); // SHTC3 Humidity screen.setCursor(0, 180); screen.println( "Hum: " ); screen.setCursor(60, 180); screen.println( humidity ); screen.setCursor(120, 180); screen.println( "%RH" ); }
getEEPROM.ino
// EEPROM // isUID EEPROM Unique ID void isUID() { // Is Unit ID uid = ""; for (int x = 0; x < 7; x++) { uid = uid + char(EEPROM.read(x)); } }
getRTC.ino
// Date and Time PCF8523 RTC // Setup Date and Time PCF8523 RTC void isSetupRTC() { // Date and Time PCF8523 RTC if (! rtc.begin()) { while (1); } if (! rtc.initialized()) { // Following line sets the RTC to the date & time this sketch was compiled rtc.adjust(DateTime(F(__DATE__), F(__TIME__))); // This line sets the RTC with an explicit date & time, for example to set // January 21, 2014 at 3am you would call: // rtc.adjust(DateTime(2024, 9, 26, 9, 1, 0)); } // When the RTC was stopped and stays connected to the battery, it has // to be restarted by clearing the STOP bit. Let's do this to ensure // the RTC is running. rtc.start(); // The PCF8523 can be calibrated for: // - Aging adjustment // - Temperature compensation // - Accuracy tuning // The offset mode to use, once every two hours or once every minute. // The offset Offset value from -64 to +63. // See the Application Note for calculation of offset values. // https://www.nxp.com/docs/en/application-note/AN11247.pdf // The deviation in parts per million can be calculated over // a period of observation. Both the drift (which can be negative) // and the observation period must be in seconds. For accuracy // the variation should be observed over about 1 week. // Note: any previous calibration should cancelled prior to // any new observation period. // Seconds plus or minus over oservation period - set to // 0 to cancel previous calibration. float drift = 43; // total obsevation period in seconds (86400 = seconds in 1 day: // 7 days = (7 * 86400) seconds ) float period_sec = (7 * 86400); // Deviation in parts per million (μs) float deviation_ppm = (drift / period_sec * 1000000); // Use with offset mode PCF8523_TwoHours float drift_unit = 4.34; //For corrections every min the drift_unit is 4.069 ppm // (use with offset mode PCF8523_OneMinute) // float drift_unit = 4.069; int offset = round(deviation_ppm / drift_unit); } // Date and Time PCF8523 RTC void isRTC () { // Date and Time DateTime now = rtc.now(); // Date dateRTC = now.year(), DEC; dateRTC = dateRTC + "/"; dateRTC = dateRTC + now.month(), DEC; dateRTC = dateRTC + "/"; dateRTC = dateRTC + now.day(), DEC; // Time timeRTC = now.hour(), DEC; timeRTC = timeRTC + ":"; timeRTC = timeRTC + now.minute(), DEC; timeRTC = timeRTC + ":"; timeRTC = timeRTC + now.second(), DEC; }
getSHTC3.ino
// SHTC3 Temperature and Humidity Sensor // SHTC3 void isSHTC3(){ // SHTC3 Temperature and Humidity Sensor /** * Mode For configuring sensor working mode * SHTC3: PRECISION_HIGH_CLKSTRETCH_ON Clock Stretching Enabled * PRECISION_HIGH_CLKSTRETCH_OFF Clock Stretching Disabled * PRECISION_LOW_CLKSTRETCH_ON Clock Stretching Enabled & Low Power * PRECISION_LOW_CLKSTRETCH_OFF Clock Stretching Disabled & Low Power */ temperature = SHTC3.getTemperature(PRECISION_HIGH_CLKSTRETCH_ON); /** * Mode For configuring sensor working mode * SHTC3 * PRECISION_HIGH_CLKSTRETCH_ON Clock Stretching Enabled * PRECISION_HIGH_CLKSTRETCH_OFF Clock Stretching Disabled * PRECISION_LOW_CLKSTRETCH_ON Clock Stretching Enabled & Low Power * PRECISION_LOW_CLKSTRETCH_OFF Clock Stretching Disabled & Low Power */ humidity = SHTC3.getHumidity(PRECISION_HIGH_CLKSTRETCH_OFF); }
getSoilMoisture.ino
// Gravity: Analog Soil Moisture Sensor // Soil Moisture void isSoilMoisture(){ // Connect Soil Moisture Sensor to Analog 0 zz = analogRead( iSoilMoisture ); // iSoilMoistureVal => 0~900 Soil Moisture iSoilMoistureVal = map( zz, 0, 4095, 0, 900); // Threshold if (iSoilMoistureVal > Threshold) // 300~950 - Humid Soil SM = "Humid Soil"; else { // 0-300 Dry Soil SM = "Dry Soil"; } }
setup.ino
// Setup void setup() { // Give display time to power on delay(100); // EEPROM Size EEPROM.begin(EEPROM_SIZE); // EEPROM Unique ID isUID(); // Delay delay( 100 ); // Wire Wire.begin(); // Delay delay( 100 ); // DFRobot Display 240x320 screen.begin(); // Delay delay(100); // Fermion: SHTC3 Temperature & Humidity Sensor SHTC3.begin(); /*SHTC3 is set to sleep mode by default. Please wake it up before use. Use SHTC3.sleep() to let SHTC3 enter sleep mode; SHTC3 stops working in sleep mode*/ SHTC3.wakeup(); // Delay delay(100); // Setup Date and Time PCF8523 RTC isSetupRTC(); // Date and Time PCF8523 RTC isRTC(); // Delay delay(100); // Initialize the LED Green pinMode(iLEDGreen, OUTPUT); // iLEDGreen HIGH digitalWrite(iLEDGreen, HIGH ); // DFRobot Display 240x320 - UID // Don Luc Electronics // Version // EEPROM isDisplayUID(); // Delay 5 Second delay( 5000 ); }
——
People can contact us: https://www.donluc.com/?page_id=1927
Electronics, IoT, Teacher, Instructor, R&D and Consulting
- Programming Language
- Single-Board Microcontrollers (PIC, Arduino, Raspberry Pi, Arm, Silicon Labs, Espressif, Etc…)
- IoT
- Wireless (Radio Frequency, Bluetooth, WiFi, Etc…)
- Robotics
- Automation
- Camera and Video Capture Receiver Stationary, Wheel/Tank and Underwater Vehicle
- Unmanned Vehicles Terrestrial and Marine
- Machine Learning
- Artificial Intelligence (AI)
- RTOS
- Sensors, eHealth Sensors, Biosensor, and Biometric
- Research & Development (R & D)
- Consulting
Follow Us
Luc Paquin – Curriculum Vitae – 2024
https://www.donluc.com/luc/
Web: https://www.donluc.com/
Facebook: https://www.facebook.com/neosteam.labs.9/
YouTube: https://www.youtube.com/@thesass2063
Twitter: https://twitter.com/labs_steam
Pinterest: https://www.pinterest.com/NeoSteamLabs/
Instagram: https://www.instagram.com/neosteamlabs/
DFRobot Luc.Paquin: https://edu.dfrobot.com/dashboard/makelogs
Hackster.io: https://www.hackster.io/neosteam-labs
ELECROW: https://www.elecrow.com/share/sharepj/center/no/760816d385ebb1edc0732fd873bfbf13
TikTok: www.tiktok.com/@luc.paquin8
LinkedIn: https://www.linkedin.com/in/jlucpaquin/
Don Luc
Project #30 – UNIHIKER – MEMS CH4 – Mk06
——
#DonLucElectronics #DonLuc #UNIHIKER #CH4 #Display #IoT #Project #Debian #Python #Thonny #DFRobot #Fritzing #Programming #Electronics #Microcontrollers #Consultant
——
——
——
——
Fermion: MEMS Methane CH4 Gas Detection Sensor
Fermion: MEMS Methane CH4 Gas Detection Sensor employs state-of-the-art micro-electromechanical system (MEMS) technology, endowing the sensor with compact dimensions, low power consumption, minimal heat generation, short preheating time, and swift response recovery. The sensor can qualitatively measure methane gas concentration and is suitable for combustible gas leakage monitoring devices, gas leak detectors, fire/safety detection systems and other applications. Detection range: 1-10000 ppm. It is advisable to preheat the module for at least 24 hours.
DL2409Mk07
1 x UNIHIKER
1 x Fermion: MEMS Methane CH4 Gas Detection Sensor
1 x USB Battery Pack
1 x USB 3.1 Cable A to C
UNIHIKER
ADC – 21
VIN – +5V
GND – GND
DL2409Mk07p
DL2409Mk07p.py
""" ****** Don Luc Electronics © ****** Software Version Information Project #30 - UNIHIKER - Fermion: MEMS CH4 - Mk06 30-06 DL2409Mk07.py DL2409Mk07 1 x UNIHIKER 1 x Fermion: MEMS Methane CH4 Gas Detection Sensor 1 x USB Battery Pack 1 x USB 3.1 Cable A to C -*- coding: utf-8 -*- """ # Import the unihiker library from unihiker import GUI # Import the time library import time # Import the Board module from the pinpong.board package from pinpong.board import Board # Import all modules from the pinpong.extension.unihiker package from pinpong.extension.unihiker import * # Initialize the board by selecting the board type and port number; # if not specified, the program will automatically detect it Board().begin() # Initialize pin 21 as analog input mode # Fermion: MEMS Methane CH4 Gas Detection Sensor adc0 = Pin(Pin.P21, Pin.ANALOG) # Instantiate the GUI class and create a gui object gui = GUI() # Display the initial background image 'DL2409Mk07p' img = gui.draw_image(x=0, y=0, w=240, h=320, image='DL2409Mk07p.png') # Fermion: MEMS Methane CH4 Gas Detection Sensor # Display the initial Fermion: MEMS Methane CH4 Gas Detection Sensor valueCH4 valueCH4 = gui.draw_text(x=30, y=151, text='0', font_size=18) while True: # Fermion: MEMS Methane CH4 Gas Detection Sensor # Read analog value CH4Sensor = adc0.read_analog() valueCH4.config(text=CH4Sensor) # Delay for 1 second to keep the screen content displayed for a longer time time.sleep(1)
——
People can contact us: https://www.donluc.com/?page_id=1927
Electronics, IoT, Teacher, Instructor, R&D and Consulting
- Programming Language
- Single-Board Microcontrollers (PIC, Arduino, Raspberry Pi, Arm, Silicon Labs, Espressif, Etc…)
- IoT
- Wireless (Radio Frequency, Bluetooth, WiFi, Etc…)
- Robotics
- Automation
- Camera and Video Capture Receiver Stationary, Wheel/Tank and Underwater Vehicle
- Unmanned Vehicles Terrestrial and Marine
- Machine Learning
- Artificial Intelligence (AI)
- RTOS
- Sensors, eHealth Sensors, Biosensor, and Biometric
- Research & Development (R & D)
- Consulting
Follow Us
Luc Paquin – Curriculum Vitae – 2024
https://www.donluc.com/luc/
Web: https://www.donluc.com/
Facebook: https://www.facebook.com/neosteam.labs.9/
YouTube: https://www.youtube.com/@thesass2063
Twitter: https://twitter.com/labs_steam
Pinterest: https://www.pinterest.com/NeoSteamLabs/
Instagram: https://www.instagram.com/neosteamlabs/
DFRobot Luc.Paquin: https://edu.dfrobot.com/dashboard/makelogs
Hackster.io: https://www.hackster.io/neosteam-labs
ELECROW: https://www.elecrow.com/share/sharepj/center/no/760816d385ebb1edc0732fd873bfbf13
TikTok: www.tiktok.com/@luc.paquin8
LinkedIn: https://www.linkedin.com/in/jlucpaquin/
Don Luc
Project #30 – UNIHIKER – MEMS VOC – Mk05
——
#DonLucElectronics #DonLuc #UNIHIKER #VOC #Display #IoT #Project #Debian #Python #Thonny #DFRobot #Fritzing #Programming #Electronics #Microcontrollers #Consultant
——
——
——
——
Fermion: MEMS Volatile Organic Compounds VOC Gas Detection Sensor
Fermion: MEMS Volatile Organic Compounds VOC Gas Sensor employs state-of-the-art microelectromechanical system (MEMS) technology, endowing the sensor with compact dimensions, low power consumption, minimal heat generation, short preheating time, and swift response recovery. The sensor can qualitatively measure VOC gas concentration and is suitable for indoor air quality detection, fresh air system, air purifier and other application scenarios. Kindly remove the protective film before usage. Gas detected: ethanol, formaldehyde, toluene, etc. Detection range: 1-500 ppm. It is advisable to preheat the module for at least 24 hours.
DL2409Mk05
1 x UNIHIKER
1 x Fermion: MEMS VOC Gas Detection Sensor
1 x USB Battery Pack
1 x USB 3.1 Cable A to C
UNIHIKER
ADC – 21
VIN – +5V
GND – GND
DL2409Mk05p
DL2409Mk05p.py
""" ****** Don Luc Electronics © ****** Software Version Information Project #30 - UNIHIKER - Fermion: MEMS VOC - Mk05 30-05 DL2409Mk05.py DL2409Mk05 1 x UNIHIKER 1 x Fermion: MEMS VOC Gas Detection Sensor 1 x USB Battery Pack 1 x USB 3.1 Cable A to C -*- coding: utf-8 -*- """ # Import the unihiker library from unihiker import GUI # Import the time library import time # Import the Board module from the pinpong.board package from pinpong.board import Board # Import all modules from the pinpong.extension.unihiker package from pinpong.extension.unihiker import * # Initialize the board by selecting the board type and port number; # if not specified, the program will automatically detect it Board().begin() # Initialize pin 21 as analog input mode # Fermion: MEMS VOC Gas Detection Sensor adc0 = Pin(Pin.P21, Pin.ANALOG) # Instantiate the GUI class and create a gui object gui = GUI() # Display the initial background image 'DL2409Mk05p' img = gui.draw_image(x=0, y=0, w=240, h=320, image='DL2409Mk05p.png') # MEMS VOC # Display the initial Fermion: MEMS VOC Gas Detection Sensor valueVOC valueVOC = gui.draw_text(x=30, y=151, text='0', font_size=18) while True: # Fermion: MEMS VOC Gas Detection Sensor # Read analog value VOCSensor = adc0.read_analog() valueVOC.config(text=VOCSensor) # Delay for 1 second to keep the screen content displayed for a longer time time.sleep(1)
——
