Project #21 – Nixie – ArduiNIX – Mk02

——

#DonLucElectronics #DonLuc #NixieTube #Nixie #ArduiNIX #ArduinoUNO #Arduino #Project #Fritzing #Programming #Electronics #Microcontrollers #Consultant

——

ArduiNIX

——

ArduiNIX

——

ArduiNIX

——

ArduiNIX

——

ArduiNIX

The ArduiNIX is an Arduino compatible shield which plugs right onto the top of the Arduino UNO board. ArduiNIX takes care of stepping power from 9 VDC wall adapter power supply up to a maximum of approximately 250 VDC to drive any and all Nixie tubes. ArduiNIX also provides Multiplexed display for up to 80 elements by using 4 anode channels and 20 cathode channels. Multiplexing increases the life expectancy of your Nixie tube investment.

Not only does the ArduiNIX provide a Nixie tube platform for standard clock functions, but it is also user programmable, meaning if you can program it using the arduino environment, you can make it happen on your Nixie display. Take special care when working with the ArduiNIX. The ArduiNIX Shield operates at high voltages. Be careful when handling it while it’s powered up. Normally the Arduino is safe to handle, but when used in conjunction with the ArduiNIX, voltages in excess of 200 volts may be achieved. Use caution. An IN-17 x 8 display board, and 8 x Russian IN-17 Nixie tubes.

DL2209Mk02

1 x Arduino UNO
1 x ArduiNIX V3 Tube Driver Shield Kit
1 x IN-17×8 V1 Tube Board Kit
1 x Anode / Cathode Connector Cable Set
1 x 9V 1000mA Power Supply
1 x SparkFun Cerberus USB Cable

Arduino UNO

SN2 – 2
SN3 – 3
SN4 – 4
SN5 – 5
SN6 – 6
SN7 – 7
SN8 – 8
SN9 – 9
AN10 – 10
AN11 – 11
AN12 – 12
AN13 – 13
VI14 – 14
VI15 – 15
VIN – +9V
GND – GND

DL2209Mk02p.ino

/* ***** Don Luc Electronics © *****
Software Version Information
Project #21 - Nixie - ArduiNIX - Mk02
21-02
DL2209Mk02p.ino
1 x Arduino UNO
1 x ArduiNIX V3 Tube Driver Shield Kit
1 x IN-17x8 V1 Tube Board Kit
1 x Anode / Cathode Connector Cable Set
1 x 9V 1000mA Power Supply
1 x SparkFun Cerberus USB Cable
*/

// Include the Library Code

// SN74141 (1)
int ledPin_0_a = 2;
int ledPin_0_b = 3;
int ledPin_0_c = 4;
int ledPin_0_d = 5;

// SN74141 (2)
int ledPin_1_a = 6;
int ledPin_1_b = 7;
int ledPin_1_c = 8;
int ledPin_1_d = 9;

// Anode pins
int ledPin_a_1 = 10;
int ledPin_a_2 = 11;
int ledPin_a_3 = 12;
int ledPin_a_4 = 13;

// NOTE: Grounding on virtual pins 14 and 15
// (analog pins 0 and 1) will set the Hour and Mins.
int iVirtual14 = 14;
int iVirtual15 = 15;

// Fade
float fadeMax = 0.1f;
float fadeStep = 0.1f;
// Number Array
int NumberArray[8]={0,0,0,0,0,0,0,0};
int currNumberArray[8]={0,0,0,0,0,0,0,0};
float NumberArrayFadeInValue[8]={0.0f,0.0f,0.0f,0.0f,0.0f,0.0f,0.0f,0.0f};
float NumberArrayFadeOutValue[8]={5.0f,5.0f,5.0f,5.0f,5.0f,5.0f,5.0f,5.0f};

// Defines
// Sub seconds
long SSECS = 100;
// Milliseconds in a Sec
long SECS = 60;
// 60 Seconds in a Min.
long MINS = 60;
// 60 Mins in an hour
long HOURS = 60 * MINS;
// 24 Hours in a day. > Note: change the 24 to a 12 for non military time.
long DAYS = 12 * HOURS;

// Time from when we started
long runTime = 0;

// Default time sets. clock will start at 12:34:00.
// This is so we can count the correct order of tubes.
long clockHourSet;
long clockMinSet;
long clockSecSet;
//long clockSSecSet;

int HourButtonPressed = false;
int MinButtonPressed = false;

// Software Version Information
String sver = "21-02";

void loop() {

  // Time
  isTime();

}

getDisplayFadeNumber.ino

// Display Fade Number
void DisplayFadeNumberString()
{

  // Anode channel 1 - numerals 0,4
  SetSN74141Chips(currNumberArray[0],currNumberArray[4]);
  digitalWrite(ledPin_a_1, HIGH);
  delay(NumberArrayFadeOutValue[0]);
  SetSN74141Chips(NumberArray[0],NumberArray[4]);
  delay(NumberArrayFadeInValue[0]);
  digitalWrite(ledPin_a_1, LOW);

    // Anode channel 2 - numerals 1,5
  SetSN74141Chips(currNumberArray[1],currNumberArray[5]);
  digitalWrite(ledPin_a_2, HIGH);
  delay(NumberArrayFadeOutValue[1]);
  SetSN74141Chips(NumberArray[1],NumberArray[5]);
  delay(NumberArrayFadeInValue[1]);
  digitalWrite(ledPin_a_2, LOW);

   // Anode channel 3 - numerals 2,6
  SetSN74141Chips(currNumberArray[2],currNumberArray[6]);
  digitalWrite(ledPin_a_3, HIGH);
  delay(NumberArrayFadeOutValue[2]);
  SetSN74141Chips(NumberArray[2],NumberArray[6]);
  delay(NumberArrayFadeInValue[2]);
  digitalWrite(ledPin_a_3, LOW);

     // Anode channel 4 - numerals 3,7
  SetSN74141Chips(currNumberArray[3],currNumberArray[7]);
  digitalWrite(ledPin_a_4, HIGH);
  delay(NumberArrayFadeOutValue[3]);
  SetSN74141Chips(NumberArray[3],NumberArray[7]);
  delay(NumberArrayFadeInValue[3]);
  digitalWrite(ledPin_a_4, LOW);

  // Loop thru and update all the arrays, and fades.
  for( int i = 0 ; i < 8 ; i ++ ) //equal to & of digits
  {
    if( NumberArray[i] != currNumberArray[i] )
    {
      NumberArrayFadeInValue[i] += fadeStep;
      NumberArrayFadeOutValue[i] -= fadeStep;

      if( NumberArrayFadeInValue[i] >= fadeMax )
      {
        NumberArrayFadeInValue[i] = 2.0f;
        NumberArrayFadeOutValue[i] = 4.0f; //affects the refresh cycle
        currNumberArray[i] = NumberArray[i];
      }
    }
  }

}

getSN74141.ino

// SN74141
// SN74141 : Truth Table
//D C B A #
//L,L,L,L 0
//L,L,L,H 1
//L,L,H,L 2
//L,L,H,H 3
//L,H,L,L 4
//L,H,L,H 5
//L,H,H,L 6
//L,H,H,H 7
//H,L,L,L 8
//H,L,L,H 9
// isSetupSN74141
void isSetupSN74141(){

  pinMode(ledPin_0_a, OUTPUT);
  pinMode(ledPin_0_b, OUTPUT);
  pinMode(ledPin_0_c, OUTPUT);
  pinMode(ledPin_0_d, OUTPUT);

  pinMode(ledPin_1_a, OUTPUT);
  pinMode(ledPin_1_b, OUTPUT);
  pinMode(ledPin_1_c, OUTPUT);
  pinMode(ledPin_1_d, OUTPUT);

  pinMode(ledPin_a_1, OUTPUT);
  pinMode(ledPin_a_2, OUTPUT);
  pinMode(ledPin_a_3, OUTPUT);
  pinMode(ledPin_a_4, OUTPUT);

  // NOTE: Grounding on virtual pins 14 and 15
  // (analog pins 0 and 1) will set the Hour and Mins.
  // Set the vertual pin 14 (pin 0 on the analog inputs )
  pinMode( iVirtual14, INPUT );
  // Set pin 14 as a pull up resistor.
  digitalWrite(iVirtual14, HIGH);
  // Set the vertual pin 15 (pin 1 on the analog inputs )
  pinMode( iVirtual15, INPUT );
  // Set pin 15 as a pull up resistor.
  digitalWrite(iVirtual15, HIGH);

}
// SetSN74141Chips
void SetSN74141Chips( int num2, int num1 )
{

  // Set defaults
  // Will display a zero.
  int a = 0;
  int b = 0;
  int c = 0;
  int d = 0;

  // Load the a,b,c,d.. to send to the SN74141 IC (1)
  switch( num1 )
  {
    case 0:
      a=0;
      b=0;
      c=0;
      d=0;
      break;
    case 1:
      a=1;
      b=0;
      c=0;
      d=0;
      break;
    case 2:
      a=0;
      b=1;
      c=0;
      d=0;
      break;
    case 3:
      a=1;
      b=1;
      c=0;
      d=0;
      break;
    case 4:
      a=0;
      b=0;
      c=1;
      d=0;
      break;
    case 5:
      a=1;
      b=0;
      c=1;
      d=0;
      break;
    case 6:
      a=0;
      b=1;
      c=1;
      d=0;
      break;
    case 7:
      a=1;
      b=1;
      c=1;
      d=0;
      break;
    case 8:
      a=0;
      b=0;
      c=0;
      d=1;
      break;
    case 9:
      a=1;
      b=0;
      c=0;
      d=1;
      break;
    default:
      a=1;
      b=1;
      c=1;
      d=1;
      break;
  }

  // Write to output pins.
  digitalWrite(ledPin_0_d, d);
  digitalWrite(ledPin_0_c, c);
  digitalWrite(ledPin_0_b, b);
  digitalWrite(ledPin_0_a, a);

  // Load the a,b,c,d.. to send to the SN74141 IC (2)
  switch( num2 )
  {
    case 0:
      a=0;
      b=0;
      c=0;
      d=0;
      break;
    case 1:
      a=1;
      b=0;
      c=0;
      d=0;
      break;
    case 2:
      a=0;
      b=1;
      c=0;
      d=0;
      break;
    case 3:
      a=1;
      b=1;
      c=0;
      d=0;
      break;
    case 4:
      a=0;
      b=0;
      c=1;
      d=0;
      break;
    case 5:
      a=1;
      b=0;
      c=1;
      d=0;
      break;
    case 6:
      a=0;
      b=1;
      c=1;
      d=0;
      break;
    case 7:
      a=1;
      b=1;
      c=1;
      d=0;
      break;
    case 8:
      a=0;
      b=0;
      c=0;
      d=1;
      break;
    case 9:
      a=1;
      b=0;
      c=0;
      d=1;
      break;
    default:
      a=1;
      b=1;
      c=1;
      d=1;
      break;
  }

  // Write to output pins
  digitalWrite(ledPin_1_d, d);
  digitalWrite(ledPin_1_c, c);
  digitalWrite(ledPin_1_b, b);
  digitalWrite(ledPin_1_a, a);

}

getTime.ino

// Time
void isTime(){

  // Get milliseconds.
  runTime = millis();
  //int ssTime = millis();

  int hourInput = digitalRead(iVirtual14);
  int minInput  = digitalRead(iVirtual15);

  if( hourInput == 0 )
    HourButtonPressed = true;
  if( minInput == 0 )
    MinButtonPressed = true;
  if( HourButtonPressed == true && hourInput == 1 )
  {
    clockHourSet++;
    HourButtonPressed = false;
  }
  if( MinButtonPressed == true && minInput == 1 )
  {
    clockMinSet++;
    MinButtonPressed = false;
  }

  // Get time in seconds.
  // Change this value to speed up or
  // slow down the clock, set to smaller number such as 10, 1, or 100 for debugging
  long time = (runTime) / 1000;
  int sstime = (runTime) / 10;
  // Set time based on offset..
  // long hbump = 60*60*clockHourSet;
  //long sbump = 60*60*60*clockHourSet; //change hourset to secondset
  long hbump = 60*60*clockHourSet;
  long mbump = 60*clockMinSet;
  time += mbump + hbump;

  // Convert time to days,hours,mins,seconds
  long days  = time / DAYS;    time -= days  * DAYS;
  long hours = time / HOURS;   time -= hours * HOURS;
  long minutes  = time / MINS;    time -= minutes  * MINS;
  long seconds  = time;
//  long sseconds  = 76;// time -= seconds  * SECS;
  long sseconds  = runTime / SECS; time -= sseconds  * SECS;

  // Get the high and low order values for hours,min,seconds.
  int lowerHours = hours % 10;
  int upperHours = hours - lowerHours;
  int lowerMins = minutes % 10;
  int upperMins = minutes - lowerMins;
  int lowerSeconds = seconds % 10;
  int upperSeconds = seconds - lowerSeconds;
  int lowerSSeconds = sseconds % 10;
  //- lowerSSeconds;
  int upperSSeconds = lowerSSeconds % 10; upperSSeconds = upperSSeconds /10;

  if( upperSSeconds >= 10 )  upperSSeconds = upperSSeconds / 10;
  if( upperSeconds >= 10 )   upperSeconds = upperSeconds / 10;
  if( upperMins >= 10 )      upperMins = upperMins / 10;
  if( upperHours >= 10 )     upperHours = upperHours / 10;

  if( upperHours == 0 && lowerHours == 0 )
  {
    upperHours = 1;
    lowerHours = 2;
  }

  // Fill in the Number array used to display on the tubes.

  NumberArray[7] = upperHours;
  NumberArray[6] = lowerHours;
  NumberArray[5] = upperMins;
  NumberArray[4] = lowerMins;
  NumberArray[3] = upperSeconds;
  NumberArray[2] = lowerSeconds;
  NumberArray[1] = lowerSSeconds; //upperSSeconds;
  NumberArray[0] = lowerSSeconds; //lowerSSeconds;

  Serial.print(lowerSSeconds);
  Serial.println();
  // Display.
  //DisplayFadeNumberString();
  // Display.
  DisplayFadeNumberString();

}

setup.ino

// Setup
void setup() {

  // isSetupSN74141
  isSetupSN74141();

  // Open serial communications
 Serial.begin(9600);

}

——

People can contact us: https://www.donluc.com/?page_id=1927

Technology Experience

  • Single-Board Microcontrollers (PIC, Arduino, Raspberry Pi,Espressif, etc…)
  • IoT
  • Robotics
  • Camera and Video Capture Receiver Stationary, Wheel/Tank and Underwater Vehicle
  • Unmanned Vehicles Terrestrial and Marine
  • Research & Development (R & D)

Instructor and E-Mentor

  • IoT
  • PIC Microcontrollers
  • Arduino
  • Raspberry Pi
  • Espressif
  • Robotics

Follow Us

J. Luc Paquin – Curriculum Vitae – 2022 English & Español
https://www.jlpconsultants.com/luc/

Web: https://www.donluc.com/
Web: https://www.jlpconsultants.com/
Facebook: https://www.facebook.com/neosteam.labs.9/
YouTube: https://www.youtube.com/channel/UC5eRjrGn1CqkkGfZy0jxEdA
Twitter: https://twitter.com/labs_steam
Pinterest: https://www.pinterest.com/NeoSteamLabs/
Instagram: https://www.instagram.com/neosteamlabs/

Don Luc

Project #21 – Nixie – Nixie Tube – Mk01

——

#DonLucElectronics #DonLuc #NixieTube #Nixie #ArduiNIX #ArduinoUNO #Arduino #Project #Fritzing #Programming #Electronics #Microcontrollers #Consultant

——

Nixie Tube

——

Nixie Tube

——

Nixie Tube

——

Nixie Tube

A Nixie tube, or cold cathode display, is an electronic device used for displaying numerals or other information using glow discharge. The glass tube contains a wire-mesh anode and multiple cathodes, shaped like numerals or other symbols. Applying power to one cathode surrounds it with an orange glow discharge. The tube is filled with a gas at low pressure.

The early Nixie displays were made by a small vacuum tube manufacturer called Haydu Brothers Laboratories, and introduced in 1955 by Burroughs Corporation, who purchased Haydu. The name Nixie was derived by Burroughs from “NIX I”, an abbreviation of “Numeric Indicator eXperimental No. 1”, although this may have been a backronym designed to justify the evocation of the mythical creature with this name.

Citing dissatisfaction with the aesthetics of modern digital displays and a nostalgic fondness for the styling of obsolete technology, significant numbers of electronics enthusiasts have shown interest in reviving Nixies.

DL2209Mk01

1 x Arduino UNO
1 x ArduiNIX V3 Tube Driver Shield Kit
1 x 9V 1000mA Power Supply
1 x SparkFun Cerberus USB Cable

Arduino UNO

SN2 – 2
SN3 – 3
SN4 – 4
SN5 – 5
SN6 – 6
SN7 – 7
SN8 – 8
SN9 – 9
AN10 – 10
AN11 – 11
AN12 – 12
AN13 – 13
VI14 – 14
VI15 – 15
VIN – +9V
GND – GND

DL2209Mk01p.ino

/* ***** Don Luc Electronics © *****
Software Version Information
Project #21 - Nixie - Nixie Tube - Mk01
21-01
DL2209Mk01p.ino
1 x Arduino UNO
1 x ArduiNIX V3 Tube Driver Shield Kit
1 x 9V 1000mA Power Supply
1 x SparkFun Cerberus USB Cable
*/

// Include the Library Code

// SN74141 (1)
int ledPin_0_a = 2;
int ledPin_0_b = 3;
int ledPin_0_c = 4;
int ledPin_0_d = 5;

// SN74141 (2)
int ledPin_1_a = 6;
int ledPin_1_b = 7;
int ledPin_1_c = 8;
int ledPin_1_d = 9;

// Anode pins
int ledPin_a_1 = 10;
int ledPin_a_2 = 11;
int ledPin_a_3 = 12;
int ledPin_a_4 = 13;

// NOTE: Grounding on virtual pins 14 and 15
// (analog pins 0 and 1) will set the Hour and Mins.
int iVirtual14 = 14;
int iVirtual15 = 15;

// Fade
float fadeMax = 0.1f;
float fadeStep = 0.1f;
// Number Array
int NumberArray[8]={0,0,0,0,0,0,0,0};
int currNumberArray[8]={0,0,0,0,0,0,0,0};
float NumberArrayFadeInValue[8]={0.0f,0.0f,0.0f,0.0f,0.0f,0.0f,0.0f,0.0f};
float NumberArrayFadeOutValue[8]={5.0f,5.0f,5.0f,5.0f,5.0f,5.0f,5.0f,5.0f};

// Defines
// Sub seconds
long SSECS = 100;
// Milliseconds in a Sec
long SECS = 60;
// 60 Seconds in a Min.
long MINS = 60;
// 60 Mins in an hour
long HOURS = 60 * MINS;
// 24 Hours in a day. > Note: change the 24 to a 12 for non military time.
long DAYS = 12 * HOURS;

// Time from when we started
long runTime = 0;

// Default time sets. clock will start at 12:34:00.
// This is so we can count the correct order of tubes.
long clockHourSet = 12;
long clockMinSet  = 34;
long clockSecSet  = 56;
long clockSSecSet  = 12;

int HourButtonPressed = false;
int MinButtonPressed = false;

// Software Version Information
String sver = "21-01";

void loop() {

  // Time
  isTime();

}

getDisplayFadeNumber.ino

// Display Fade Number
void DisplayFadeNumberString()
{

  // Anode channel 1 - numerals 0,4
  SetSN74141Chips(currNumberArray[0],currNumberArray[4]);
  digitalWrite(ledPin_a_1, HIGH);
  delay(NumberArrayFadeOutValue[0]);
  SetSN74141Chips(NumberArray[0],NumberArray[4]);
  delay(NumberArrayFadeInValue[0]);
  digitalWrite(ledPin_a_1, LOW);

    // Anode channel 2 - numerals 1,5
  SetSN74141Chips(currNumberArray[1],currNumberArray[5]);
  digitalWrite(ledPin_a_2, HIGH);
  delay(NumberArrayFadeOutValue[1]);
  SetSN74141Chips(NumberArray[1],NumberArray[5]);
  delay(NumberArrayFadeInValue[1]);
  digitalWrite(ledPin_a_2, LOW);

   // Anode channel 3 - numerals 2,6
  SetSN74141Chips(currNumberArray[2],currNumberArray[6]);
  digitalWrite(ledPin_a_3, HIGH);
  delay(NumberArrayFadeOutValue[2]);
  SetSN74141Chips(NumberArray[2],NumberArray[6]);
  delay(NumberArrayFadeInValue[2]);
  digitalWrite(ledPin_a_3, LOW);

     // Anode channel 4 - numerals 3,7
  SetSN74141Chips(currNumberArray[3],currNumberArray[7]);
  digitalWrite(ledPin_a_4, HIGH);
  delay(NumberArrayFadeOutValue[3]);
  SetSN74141Chips(NumberArray[3],NumberArray[7]);
  delay(NumberArrayFadeInValue[3]);
  digitalWrite(ledPin_a_4, LOW);

  // Loop thru and update all the arrays, and fades.
  for( int i = 0 ; i < 8 ; i ++ ) //equal to & of digits
  {
    if( NumberArray[i] != currNumberArray[i] )
    {
      NumberArrayFadeInValue[i] += fadeStep;
      NumberArrayFadeOutValue[i] -= fadeStep;

      if( NumberArrayFadeInValue[i] >= fadeMax )
      {
        NumberArrayFadeInValue[i] = 2.0f;
        NumberArrayFadeOutValue[i] = 4.0f; //affects the refresh cycle
        currNumberArray[i] = NumberArray[i];
      }
    }
  }

}

getSN74141.ino

// SN74141
// SN74141 : Truth Table
//D C B A #
//L,L,L,L 0
//L,L,L,H 1
//L,L,H,L 2
//L,L,H,H 3
//L,H,L,L 4
//L,H,L,H 5
//L,H,H,L 6
//L,H,H,H 7
//H,L,L,L 8
//H,L,L,H 9
// isSetupSN74141
void isSetupSN74141(){

  pinMode(ledPin_0_a, OUTPUT);
  pinMode(ledPin_0_b, OUTPUT);
  pinMode(ledPin_0_c, OUTPUT);
  pinMode(ledPin_0_d, OUTPUT);

  pinMode(ledPin_1_a, OUTPUT);
  pinMode(ledPin_1_b, OUTPUT);
  pinMode(ledPin_1_c, OUTPUT);
  pinMode(ledPin_1_d, OUTPUT);

  pinMode(ledPin_a_1, OUTPUT);
  pinMode(ledPin_a_2, OUTPUT);
  pinMode(ledPin_a_3, OUTPUT);
  pinMode(ledPin_a_4, OUTPUT);

  // NOTE: Grounding on virtual pins 14 and 15
  // (analog pins 0 and 1) will set the Hour and Mins.
  // Set the vertual pin 14 (pin 0 on the analog inputs )
  pinMode( iVirtual14, INPUT );
  // Set pin 14 as a pull up resistor.
  digitalWrite(iVirtual14, HIGH);
  // Set the vertual pin 15 (pin 1 on the analog inputs )
  pinMode( iVirtual15, INPUT );
  // Set pin 15 as a pull up resistor.
  digitalWrite(iVirtual15, HIGH);

}
// SetSN74141Chips
void SetSN74141Chips( int num2, int num1 )
{

  // Set defaults
  // Will display a zero.
  int a = 0;
  int b = 0;
  int c = 0;
  int d = 0;

  // Load the a,b,c,d.. to send to the SN74141 IC (1)
  switch( num1 )
  {
    case 0:
      a=0;
      b=0;
      c=0;
      d=0;
      break;
    case 1:
      a=1;
      b=0;
      c=0;
      d=0;
      break;
    case 2:
      a=0;
      b=1;
      c=0;
      d=0;
      break;
    case 3:
      a=1;
      b=1;
      c=0;
      d=0;
      break;
    case 4:
      a=0;
      b=0;
      c=1;
      d=0;
      break;
    case 5:
      a=1;
      b=0;
      c=1;
      d=0;
      break;
    case 6:
      a=0;
      b=1;
      c=1;
      d=0;
      break;
    case 7:
      a=1;
      b=1;
      c=1;
      d=0;
      break;
    case 8:
      a=0;
      b=0;
      c=0;
      d=1;
      break;
    case 9:
      a=1;
      b=0;
      c=0;
      d=1;
      break;
    default:
      a=1;
      b=1;
      c=1;
      d=1;
      break;
  }

  // Write to output pins.
  digitalWrite(ledPin_0_d, d);
  digitalWrite(ledPin_0_c, c);
  digitalWrite(ledPin_0_b, b);
  digitalWrite(ledPin_0_a, a);

  // Load the a,b,c,d.. to send to the SN74141 IC (2)
  switch( num2 )
  {
    case 0:
      a=0;
      b=0;
      c=0;
      d=0;
      break;
    case 1:
      a=1;
      b=0;
      c=0;
      d=0;
      break;
    case 2:
      a=0;
      b=1;
      c=0;
      d=0;
      break;
    case 3:
      a=1;
      b=1;
      c=0;
      d=0;
      break;
    case 4:
      a=0;
      b=0;
      c=1;
      d=0;
      break;
    case 5:
      a=1;
      b=0;
      c=1;
      d=0;
      break;
    case 6:
      a=0;
      b=1;
      c=1;
      d=0;
      break;
    case 7:
      a=1;
      b=1;
      c=1;
      d=0;
      break;
    case 8:
      a=0;
      b=0;
      c=0;
      d=1;
      break;
    case 9:
      a=1;
      b=0;
      c=0;
      d=1;
      break;
    default:
      a=1;
      b=1;
      c=1;
      d=1;
      break;
  }

  // Write to output pins
  digitalWrite(ledPin_1_d, d);
  digitalWrite(ledPin_1_c, c);
  digitalWrite(ledPin_1_b, b);
  digitalWrite(ledPin_1_a, a);

}

getTime.ino

// Time
void isTime(){

  // Get milliseconds.
  runTime = millis();
  //int ssTime = millis();

  int hourInput = digitalRead(iVirtual14);
  int minInput  = digitalRead(iVirtual15);

  if( hourInput == 0 )
    HourButtonPressed = true;
  if( minInput == 0 )
    MinButtonPressed = true;
  if( HourButtonPressed == true && hourInput == 1 )
  {
    clockHourSet++;
    HourButtonPressed = false;
  }
  if( MinButtonPressed == true && minInput == 1 )
  {
    clockMinSet++;
    MinButtonPressed = false;
  }

  // Get time in seconds.
  // Change this value to speed up or
  // slow down the clock, set to smaller number such as 10, 1, or 100 for debugging
  long time = (runTime) / 1000;
  int sstime = (runTime) / 10;
  // Set time based on offset..
  // long hbump = 60*60*clockHourSet;
  //long sbump = 60*60*60*clockHourSet; //change hourset to secondset
  long hbump = 60*60*clockHourSet;
  long mbump = 60*clockMinSet;
  time += mbump + hbump;

  // Convert time to days,hours,mins,seconds
  long days  = time / DAYS;    time -= days  * DAYS;
  long hours = time / HOURS;   time -= hours * HOURS;
  long minutes  = time / MINS;    time -= minutes  * MINS;
  long seconds  = time;
//  long sseconds  = 76;// time -= seconds  * SECS;
  long sseconds  = runTime / SECS; time -= sseconds  * SECS;

  // Get the high and low order values for hours,min,seconds.
  int lowerHours = hours % 10;
  int upperHours = hours - lowerHours;
  int lowerMins = minutes % 10;
  int upperMins = minutes - lowerMins;
  int lowerSeconds = seconds % 10;
  int upperSeconds = seconds - lowerSeconds;
  int lowerSSeconds = sseconds % 10;
  //- lowerSSeconds;
  int upperSSeconds = lowerSSeconds % 10; upperSSeconds = upperSSeconds /10;

  if( upperSSeconds >= 10 )  upperSSeconds = upperSSeconds / 10;
  if( upperSeconds >= 10 )   upperSeconds = upperSeconds / 10;
  if( upperMins >= 10 )      upperMins = upperMins / 10;
  if( upperHours >= 10 )     upperHours = upperHours / 10;

  if( upperHours == 0 && lowerHours == 0 )
  {
    upperHours = 1;
    lowerHours = 2;
  }

  // Fill in the Number array used to display on the tubes.

  NumberArray[7] = upperHours;
  NumberArray[6] = lowerHours;
  NumberArray[5] = upperMins;
  NumberArray[4] = lowerMins;
  NumberArray[3] = upperSeconds;
  NumberArray[2] = lowerSeconds;
  NumberArray[1] = lowerSSeconds; //upperSSeconds;
  NumberArray[0] = lowerSSeconds; //lowerSSeconds;

  Serial.print(lowerSSeconds);
  Serial.println();
  // Display.
  //DisplayFadeNumberString();
  // Display.
  DisplayFadeNumberString();

}

setup.ino

// Setup
void setup() {

  // isSetupSN74141
  isSetupSN74141();

  // Open serial communications
 Serial.begin(9600);

}

——

People can contact us: https://www.donluc.com/?page_id=1927

Technology Experience

  • Single-Board Microcontrollers (PIC, Arduino, Raspberry Pi,Espressif, etc…)
  • IoT
  • Robotics
  • Camera and Video Capture Receiver Stationary, Wheel/Tank and Underwater Vehicle
  • Unmanned Vehicles Terrestrial and Marine
  • Research & Development (R & D)

Instructor and E-Mentor

  • IoT
  • PIC Microcontrollers
  • Arduino
  • Raspberry Pi
  • Espressif
  • Robotics

Follow Us

J. Luc Paquin – Curriculum Vitae – 2022 English & Español
https://www.jlpconsultants.com/luc/

Web: https://www.donluc.com/
Web: https://www.jlpconsultants.com/
Facebook: https://www.facebook.com/neosteam.labs.9/
YouTube: https://www.youtube.com/channel/UC5eRjrGn1CqkkGfZy0jxEdA
Twitter: https://twitter.com/labs_steam
Pinterest: https://www.pinterest.com/NeoSteamLabs/
Instagram: https://www.instagram.com/neosteamlabs/

Don Luc

Project #22: Synthesizer – Gain – Mk14

——

#DonLucElectronics #DonLuc #Synthesizer #Mozzi #Keyboard #ADSREnvelope #Arduino #SparkFunRedBoard #Project #Fritzing #Programming #Electronics #Microcontrollers #Consultant

——

Gain

——

Gain

——

Gain

——

Gain

Gain is the process of managing the relative levels in each step of an audio signal flow to prevent introduction of noise and distortion, particularly in the analogue realm. Ideal gain occurs when each component in an audio signal flow is receiving and transmitting signal in the optimum region of its dynamic range.

Before we can effectively compare these two properties of audio, we need to make sure we understand what each is separately. Keep in mind that both modulate the amplitude of a signal, which translates into a change in loudness. It gets more complicated, dealing with voltage and current in electronics. Amplitude is measured in voltage, which is a direct corollary to volume. In plain language, gain is kind of like an amplitude knob at the input of a piece of hardware or software that controls the loudness before it goes through the circuitry.

DL2208Mk07

1 x SparkFun RedBoard
1 x 10k Ohm Rotary Potentiometer
1 x Potentiometer Knob – Blue
7 x Momentary Button – Panel Mount (Blue)
5 x Momentary Button – Panel Mount (Black)
12 x 10K Ohm Resistor
5 x 10k Ohm Slide Linear Taper Pot – X-Large
5 x Slide Potentiometer Knob – X-Large
1 x Perfboard 13.5 cm x 11 cm
1 x SparkFun Solderable Breadboard
1 x Audio Jack 3.5mm
1 x SparkFun Audio Jack Breakout
1 x SparkFun ProtoShield
1 x Insignia Speakers
1 x SparkFun Cerberus USB Cable

SparkFun RedBoard

LP0 – Analog A0 – Blue
LP1 – Analog A1 – Green
LP2 – Analog A2 – Grey
LP3 – Analog A3 – Yellow
LP4 – Analog A4 – Purple
PO5 – Analog A5
KY1 – 1
KY2 – 2
KY3 – 3
KY4 – 4
KY5 – 5
KY6 – 6
KY7 – 7
KY8 – 8
SPK – 9
KY10 – 10
KY11 – 11
KY12 – 12
KY13 – 13
VIN – +5V
GND – GND

——

DL2208Mk07p.ino

/* ***** Don Luc Electronics © *****
Software Version Information
Project #22: Synthesizer - Gain - Mk14
22-14
DL2208Mk07p.ino
1 x SparkFun RedBoard
1 x 10k Ohm Rotary Potentiometer
1 x Potentiometer Knob - Blue
7 x Momentary Button - Panel Mount (Blue)
5 x Momentary Button - Panel Mount (Black)
12 x 1K Ohm Resistor
5 x 10k Ohm Slide Linear Taper Pot - X-Large
5 x Slide Potentiometer Knob - X-Large
1 x Perfboard 13.5 cm x 11 cm
1 x SparkFun Solderable Breadboard
1 x Audio Jack 3.5mm
1 x SparkFun Audio Jack Breakout
1 x SparkFun ProtoShield
1 x Insignia Speakers
1 x SparkFun Cerberus USB Cable
*/

// Include the Library Code
// Pitches
#include "pitches.h"
// Mozzi
#include <MozziGuts.h>
// Oscillator
#include <Oscil.h>
// Sine Wave Table For Oscillator
#include <tables/sin2048_int8.h>
// Cosine Wave Table For Oscillator
#include <tables/cos2048_int8.h>
// Sawtooth Wave Table For Oscillator
#include <tables/saw2048_int8.h>
// Triangle Wave Table For Oscillator
#include <tables/triangle2048_int8.h>
// Square Wave Table For Oscillator
#include <tables/square_no_alias_2048_int8.h>
// ADSR envelope generator
#include <ADSR.h>

// Simple Keyboard
// Minimum reading of the button that generates a note
const int iKeyboard1 = 1;
const int iKeyboard2 = 2;
const int iKeyboard3 = 3;
const int iKeyboard4 = 4;
const int iKeyboard5 = 5;
const int iKeyboard6 = 6;
const int iKeyboard7 = 7;
const int iKeyboard8 = 8;
const int iKeyboard10 = 10;
const int iKeyboard11 = 11;
const int iKeyboard12 = 12;
const int iKeyboard13 = 13;
// Button is pressed
int iB1 = 1;
int iB2 = 1;
int iB3 = 1;
int iB4 = 1;
int iB5 = 1;
int iB6 = 1;
int iB7 = 1;
int iB8 = 1;
int iB10 = 1;
int iB11 = 1;
int iB12 = 1;
int iB13 = 1;

// Set the input for the potentiometer for Frequency to analog pin 2
const int potFreq = A2;
int iFreg = 1;
int iNoteA = 0;
int iNoteAS = 0;
int iNoteB = 0;
int iNoteC = 0;
int iNoteCS = 0;
int iNoteD = 0;
int iNoteDS = 0;
int iNoteE = 0;
int iNoteF = 0;
int iNoteFS = 0;
int iNoteG = 0;
int iNoteGS = 0;

// Gain
const int iGainPot4 = A4;
// Control variable, use the smallest data size you can for anything used in audio
byte gain = 0;
int iGain = 0;

//Oscillator Functions declared for output envelope 1
// Carrier
Oscil<COS2048_NUM_CELLS, AUDIO_RATE> aCarrier;
// Set the input for the potentiometer for Oscillator to analog pin 4
const int potWave = A5;
// Wave
int iWave;
int iWaveLevel;

// ADSR declaration/definition
// Comment out to use control rate of 128
#define CONTROL_RATE 128
ADSR <CONTROL_RATE, CONTROL_RATE> envelope1;

// Set the input for the potentiometer Attack to analog pin 1
const int potAttack = A0;
// Attack
int attack_level = 0;
int iAttack = 0;

// Set the input for the potentiometer for Decay to analog pin 2
const int potDecay = A1;
// Decay
int decay_level = 0;
int iDecay = 0;

// Set the input for the potentiometer Attack Time to analog pin 3
const int potAttackTime = A3;
// Attack Time
int AttackTime_level = 0;
int iAttackTime = 0;

// Software Version Information
String sver = "22-14";

void loop() {

  // Audio Hook
  audioHook();

}

getKeyboard.ino

// getKeyboard
// setupKeyboard
void setupKeyboard() {

  // Initialize the button pin as an input
  pinMode(iKeyboard1, INPUT_PULLUP);
  pinMode(iKeyboard2, INPUT_PULLUP);
  pinMode(iKeyboard3, INPUT_PULLUP);
  pinMode(iKeyboard4, INPUT_PULLUP);
  pinMode(iKeyboard5, INPUT_PULLUP);
  pinMode(iKeyboard6, INPUT_PULLUP);
  pinMode(iKeyboard7, INPUT_PULLUP);
  pinMode(iKeyboard8, INPUT_PULLUP);
  pinMode(iKeyboard10, INPUT_PULLUP);
  pinMode(iKeyboard11, INPUT_PULLUP);
  pinMode(iKeyboard12, INPUT_PULLUP);
  pinMode(iKeyboard13, INPUT_PULLUP);

}
// isKeyboard
void isKeyboard() {

  // Oscillators
  isOscil();
  // Choose envelope levels
  // attack_level
  iAttack = mozziAnalogRead( potAttack );
  attack_level = map( iAttack, 0, 1023, 100, 400);
  // Attack Level
  envelope1.setAttackLevel( attack_level );
  // decay_level
  iDecay = mozziAnalogRead( potDecay );
  decay_level = map( iDecay, 0, 1023, 50, 255);
  // Decay Level
  envelope1.setDecayLevel( decay_level );
  // AttackTime_level
  iAttackTime = mozziAnalogRead( potAttackTime );
  AttackTime_level = map( iAttackTime, 0, 1023, 0, 900);
  // Attack Time Level
  envelope1.setAttackTime( AttackTime_level );

  // Read the state of the button value 1
  if ( digitalRead(iKeyboard1) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 1
    iB1 = iB1 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aCarrier.setFreq(iNoteA);

  }
  else
  {

    iB1 = iB1 - 1;

  }

  // Read the state of the button value 2
  if ( digitalRead(iKeyboard2) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 2
    iB2 = iB2 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aCarrier.setFreq(iNoteAS);

  }
  else
  {

    iB2 = iB2 - 1;

  }

  // Read the state of the button value 3
  if ( digitalRead(iKeyboard3) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 3
    iB3 = iB3 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aCarrier.setFreq(iNoteB);

  }
  else
  {

    iB3 = iB3 - 1;

  }

  // Read the state of the button value 4
  if ( digitalRead(iKeyboard4) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 4
    iB4 = iB4 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aCarrier.setFreq(iNoteC);

  }
  else
  {

    iB4 = iB4 - 1;

  }

  // Read the state of the button value 5
  if ( digitalRead(iKeyboard5) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 5
    iB5 = iB5 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aCarrier.setFreq(iNoteCS);

  }
  else
  {

    iB5 = iB5 - 1;

  }

  // Read the state of the button value 6
  if ( digitalRead(iKeyboard6) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 6
    iB6 = iB6 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aCarrier.setFreq(iNoteD);

  }
  else
  {

    iB6 = iB6 - 1;

  }

  // Read the state of the button value 7
  if ( digitalRead(iKeyboard7) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 7
    iB7 = iB7 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aCarrier.setFreq(iNoteDS);

  }
  else
  {

    iB7 = iB7 - 1;

  }

  // Read the state of the button value 8
  if ( digitalRead(iKeyboard8) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 8
    iB8 = iB8 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aCarrier.setFreq(iNoteE);

  }
  else
  {

    iB8 = iB8 - 1;

  }

  // Read the state of the button value 10
  if ( digitalRead(iKeyboard10) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 10
    iB10 = iB10 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aCarrier.setFreq(iNoteF);

  }
  else
  {

    iB10 = iB10 - 1;

  }

  // Read the state of the button value 11
  if ( digitalRead(iKeyboard11) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 11
    iB11 = iB11 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aCarrier.setFreq(iNoteFS);

  }
  else
  {

    iB11 = iB11 - 1;

  }

  // Read the state of the button value 12
  if ( digitalRead(iKeyboard12) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 12
    iB12 = iB12 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aCarrier.setFreq(iNoteG);

  }
  else
  {

    iB12 = iB12 - 1;

  }

  // Read the state of the button value 13
  if ( digitalRead(iKeyboard13) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 13
    iB13 = iB13 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aCarrier.setFreq(iNoteGS);

  }
  else
  {

    iB13 = iB13 - 1;

  }

}

getMozzi.ino

// Mozzi
// Update Control
void updateControl(){

  // Frequency
  isPitches();

  // Keyboard
  isKeyboard();

  // Gain
  // As byte, this will automatically roll around to 255 when it passes 0
  iGain = mozziAnalogRead( iGainPot4 );
  gain = map( iGain, 0, 1023, 0, 255);

}
// Update Audio
int updateAudio()
{

  // Update Audio
  // ADSR declaration/definition
  envelope1.update();
  // >>8 for AUDIO_MODE STANDARD
  return (int) (envelope1.next() * aCarrier.next() * gain)>>8;

}

getOscillators.ino

// Oscillators
// isOscil
void isOscil(){

  // Oscillators
  // Value is 0-1023
  iWave = mozziAnalogRead(potWave);
  iWaveLevel = map(iWave, 0, 1023, 1, 5);

  switch (iWaveLevel) {
    case 1:
      // Sine Wave
      aCarrier.setTable(SIN2048_DATA);
      break;
    case 2:
      // Cosine Wave
      aCarrier.setTable(COS2048_DATA);
      break;
    case 3:
      // Sawtooth Wave
      aCarrier.setTable(SAW2048_DATA);
      break;
    case 4:
      // Triangle Wave
      aCarrier.setTable(TRIANGLE2048_DATA);
      break;
    case 5:
      // Square Wave
      aCarrier.setTable(SQUARE_NO_ALIAS_2048_DATA);
      break;
    default: // Case 0
      // Sine Wave
      aCarrier.setTable(SIN2048_DATA);
      break;
  }

}

getPitches.ino

// Pitches
// isPitches
void isPitches(){

  // Frequency
  // Value is 0-1023
  iFreg = mozziAnalogRead(potFreq);
  iFreg = map(iFreg, 0, 1023, 2, 5);

  // Range Frequency Note Low => High
  switch ( iFreg ) {
    case 1:
      // NOTE A1
      iNoteA = NOTE_A1;
      iNoteAS = NOTE_AS1;
      iNoteB = NOTE_B1;
      iNoteC = NOTE_C2;
      iNoteCS = NOTE_CS2;
      iNoteD = NOTE_D2;
      iNoteDS = NOTE_DS2;
      iNoteE = NOTE_E2;
      iNoteF = NOTE_F2;
      iNoteFS = NOTE_FS2;
      iNoteG = NOTE_G2;
      iNoteGS = NOTE_GS2;
      break;
    case 2:
      // NOTE A2
      iNoteA = NOTE_A2;
      iNoteAS = NOTE_AS2;
      iNoteB = NOTE_B2;
      iNoteC = NOTE_C3;
      iNoteCS = NOTE_CS3;
      iNoteD = NOTE_D3;
      iNoteDS = NOTE_DS3;
      iNoteE = NOTE_E3;
      iNoteF = NOTE_F3;
      iNoteFS = NOTE_FS3;
      iNoteG = NOTE_G3;
      iNoteGS = NOTE_GS3;
      break;
    case 3:
      // NOTE A3
      iNoteA = NOTE_A3;
      iNoteAS = NOTE_AS3;
      iNoteB = NOTE_B3;
      iNoteC = NOTE_C4;
      iNoteD = NOTE_D4;
      iNoteDS = NOTE_DS4;
      iNoteE = NOTE_E4;
      iNoteF = NOTE_F4;
      iNoteFS = NOTE_FS4;
      iNoteG = NOTE_G4;
      iNoteGS = NOTE_GS4;
      break;
    case 4:
      // NOTE A4
      iNoteA = NOTE_A4;
      iNoteAS = NOTE_AS4;
      iNoteB = NOTE_B4;
      iNoteC = NOTE_C5;
      iNoteCS = NOTE_CS5;
      iNoteD = NOTE_D5;
      iNoteE = NOTE_E5;
      iNoteF = NOTE_F5;
      iNoteFS = NOTE_FS5;
      iNoteG = NOTE_G5;
      iNoteGS = NOTE_GS5;
      break;
    case 5:
      // NOTE A5
      iNoteA = NOTE_A5;
      iNoteAS = NOTE_AS5;
      iNoteB = NOTE_B5;
      iNoteC = NOTE_C6;
      iNoteCS = NOTE_CS6;
      iNoteD = NOTE_D6;
      iNoteDS = NOTE_DS6;
      iNoteE = NOTE_E6;
      iNoteF = NOTE_F6;
      iNoteFS = NOTE_FS6;
      iNoteG = NOTE_G6;
      iNoteGS = NOTE_GS6;
      break;
    case 6:
      // NOTE A6
      iNoteA = NOTE_A6;
      iNoteAS = NOTE_AS6;
      iNoteB = NOTE_B6;
      iNoteC = NOTE_C7;
      iNoteCS = NOTE_CS7;
      iNoteD = NOTE_D7;
      iNoteDS = NOTE_DS7;
      iNoteE = NOTE_E7;
      iNoteF = NOTE_F7;
      iNoteFS = NOTE_FS7;
      iNoteG = NOTE_G7;
      iNoteGS = NOTE_GS7;
      break;
  }

}

pitches.h

/*****************************************************************
 * Pitches NOTE_B0 <=> NOTE_DS8 - NOTE_A4 is "A" measured at 440Hz
 *****************************************************************/

#define NOTE_B0  31
#define NOTE_C1  33
#define NOTE_CS1  35
#define NOTE_D1  37
#define NOTE_DS1  39
#define NOTE_E1  41
#define NOTE_F1  44
#define NOTE_FS1  46
#define NOTE_G1  49
#define NOTE_GS1  52
#define NOTE_A1  55
#define NOTE_AS1  58
#define NOTE_B1  62
#define NOTE_C2  65
#define NOTE_CS2  69
#define NOTE_D2  73
#define NOTE_DS2  78
#define NOTE_E2  82
#define NOTE_F2  87
#define NOTE_FS2  93
#define NOTE_G2  98
#define NOTE_GS2  104
#define NOTE_A2  110
#define NOTE_AS2  117
#define NOTE_B2  123
#define NOTE_C3  131
#define NOTE_CS3  139
#define NOTE_D3  147
#define NOTE_DS3  156
#define NOTE_E3  165
#define NOTE_F3  175
#define NOTE_FS3 185
#define NOTE_G3  196
#define NOTE_GS3  208
#define NOTE_A3  220
#define NOTE_AS3  233
#define NOTE_B3  247
#define NOTE_C4  262
#define NOTE_CS4  277
#define NOTE_D4  294
#define NOTE_DS4 311
#define NOTE_E4  330
#define NOTE_F4  349
#define NOTE_FS4  370
#define NOTE_G4  392
#define NOTE_GS4  415
#define NOTE_A4  440
#define NOTE_AS4  466
#define NOTE_B4  494
#define NOTE_C5  523
#define NOTE_CS5  554
#define NOTE_D5  587
#define NOTE_DS5  622
#define NOTE_E5  659
#define NOTE_F5  698
#define NOTE_FS5  740
#define NOTE_G5  784
#define NOTE_GS5  831
#define NOTE_A5  880
#define NOTE_AS5  932
#define NOTE_B5  988
#define NOTE_C6  1047
#define NOTE_CS6  1109
#define NOTE_D6  1175
#define NOTE_DS6  1245
#define NOTE_E6  1319
#define NOTE_F6  1397
#define NOTE_FS6  1480
#define NOTE_G6  1568
#define NOTE_GS6  1661
#define NOTE_A6  1760
#define NOTE_AS6  1865
#define NOTE_B6  1976
#define NOTE_C7  2093
#define NOTE_CS7  2217
#define NOTE_D7  2349
#define NOTE_DS7  2489
#define NOTE_E7  2637
#define NOTE_F7  2794
#define NOTE_FS7  2960
#define NOTE_G7  3136
#define NOTE_GS7  3322
#define NOTE_A7  3520
#define NOTE_AS7  3729
#define NOTE_B7  3951
#define NOTE_C8  4186
#define NOTE_CS8  4435
#define NOTE_D8  4699
#define NOTE_DS8  4978

setup.ino

// Setup
void setup() {

  // Setup Keyboard
  setupKeyboard();

  // Mozzi Start
  startMozzi( CONTROL_RATE );
  // Sets Attack and Decay Levels; assumes Sustain, Decay, and Idle times
  envelope1.setADLevels(200,200);
  // Sets Decay time in milliseconds
  envelope1.setDecayTime(200);
  // Sustain Time setting for envelope1
  envelope1.setSustainTime(52500);

}

——

People can contact us: https://www.donluc.com/?page_id=1927

Technology Experience

  • Single-Board Microcontrollers (PIC, Arduino, Raspberry Pi,Espressif, etc…)
  • IoT
  • Robotics
  • Camera and Video Capture Receiver Stationary, Wheel/Tank and Underwater Vehicle
  • Unmanned Vehicles Terrestrial and Marine
  • Research & Development (R & D)

Instructor and E-Mentor

  • IoT
  • PIC Microcontrollers
  • Arduino
  • Raspberry Pi
  • Espressif
  • Robotics

Follow Us

J. Luc Paquin – Curriculum Vitae – 2022 English & Español
https://www.jlpconsultants.com/luc/

Web: https://www.donluc.com/
Web: https://www.jlpconsultants.com/
Facebook: https://www.facebook.com/neosteam.labs.9/
YouTube: https://www.youtube.com/channel/UC5eRjrGn1CqkkGfZy0jxEdA
Twitter: https://twitter.com/labs_steam
Pinterest: https://www.pinterest.com/NeoSteamLabs/
Instagram: https://www.instagram.com/neosteamlabs/

Don Luc

Project #22: Synthesizer – Attack Time Level – Mk12

——

#DonLucElectronics #DonLuc #Synthesizer #Mozzi #Keyboard #ADSREnvelope #Arduino #SparkFunRedBoard #Project #Fritzing #Programming #Electronics #Microcontrollers #Consultant

——

Attack Time Level

——

Attack Time Level

——

Attack Time Level

——

Attack Time Level

When creating artificial waveforms in a synthesizer, changes in the signal amplitude over time are controlled by an envelope generator which typically has controls to adjust the Attack, Decay, Sustain and Release times, triggered by the pressing and subsequent release of a key on the keyboard. The Attack Time Level determines the time taken for the signal to grow to its maximum amplitude, initiated by the pressing of a key. By lengthening the attack and release times, you can create rich, lush tones. By shortening the time of the attack and release phases, you can create percussive, staccato sounds.

DL2208Mk05

1 x SparkFun RedBoard
7 x Momentary Button – Panel Mount (Blue)
5 x Momentary Button – Panel Mount (Black)
12 x 10K Ohm Resistor
5 x 10k Ohm Slide Linear Taper Pot – X-Large
5 x Slide Potentiometer Knob – X-Large
1 x Perfboard 13.5 cm x 11 cm
1 x SparkFun Solderable Breadboard
1 x Audio Jack 3.5mm
1 x SparkFun Audio Jack Breakout
1 x SparkFun ProtoShield
1 x Insignia Speakers
1 x SparkFun Cerberus USB Cable

SparkFun RedBoard

LP0 – Analog A0 – Blue
LP1 – Analog A1 – Green
LP2 – Analog A2 – Grey
LP3 – Analog A3 – Yellow
LP4 – Analog A4 – Purple
KY1 – 1
KY2 – 2
KY3 – 3
KY4 – 4
KY5 – 5
KY6 – 6
KY7 – 7
KY8 – 8
SPK – 9
KY10 – 10
KY11 – 11
KY12 – 12
KY13 – 13
VIN – +5V
GND – GND

——

DL2208Mk05p.ino

/* ***** Don Luc Electronics © *****
Software Version Information
Project #22: Synthesizer - Attack Time Level - Mk12
22-12
DL2208Mk05p.ino
1 x SparkFun RedBoard
7 x Momentary Button - Panel Mount (Blue)
5 x Momentary Button - Panel Mount (Black)
12 x 1K Ohm Resistor
5 x 10k Ohm Slide Linear Taper Pot - X-Large
5 x Slide Potentiometer Knob - X-Large
1 x Perfboard 13.5 cm x 11 cm
1 x SparkFun Solderable Breadboard
1 x Audio Jack 3.5mm
1 x SparkFun Audio Jack Breakout
1 x SparkFun ProtoShield
1 x Insignia Speakers
1 x SparkFun Cerberus USB Cable
*/

// Include the Library Code
// Pitches
#include "pitches.h"
// Mozzi
#include <MozziGuts.h>
// Oscillator
#include <Oscil.h>
// Sine Wave Table For Oscillator
#include <tables/sin2048_int8.h>
// ADSR envelope generator
#include <ADSR.h>

// Simple Keyboard
// Minimum reading of the button that generates a note
const int iKeyboard1 = 1;
const int iKeyboard2 = 2;
const int iKeyboard3 = 3;
const int iKeyboard4 = 4;
const int iKeyboard5 = 5;
const int iKeyboard6 = 6;
const int iKeyboard7 = 7;
const int iKeyboard8 = 8;
const int iKeyboard10 = 10;
const int iKeyboard11 = 11;
const int iKeyboard12 = 12;
const int iKeyboard13 = 13;
// Button is pressed
int iB1 = 1;
int iB2 = 1;
int iB3 = 1;
int iB4 = 1;
int iB5 = 1;
int iB6 = 1;
int iB7 = 1;
int iB8 = 1;
int iB10 = 1;
int iB11 = 1;
int iB12 = 1;
int iB13 = 1;

// Set the input for the potentiometer for Frequency to analog pin 2
const int potFreq = A2;
int iFreg = 1;
int iNoteA = 0;
int iNoteAS = 0;
int iNoteB = 0;
int iNoteC = 0;
int iNoteCS = 0;
int iNoteD = 0;
int iNoteDS = 0;
int iNoteE = 0;
int iNoteF = 0;
int iNoteFS = 0;
int iNoteG = 0;
int iNoteGS = 0;

// Potentiometer
int iPot4 = A4;

//Oscillator Functions declared for output envelope 1
// Sine Wave
Oscil <2048, AUDIO_RATE> aSin1(SIN2048_DATA);

// ADSR declaration/definition
// Comment out to use control rate of 128
#define CONTROL_RATE 128
ADSR <CONTROL_RATE, CONTROL_RATE> envelope1;

// Set the input for the potentiometer Attack to analog pin 1
const int potAttack = A0;
// Attack
int attack_level = 0;
int iAttack = 0;

// Set the input for the potentiometer for Decay to analog pin 2
const int potDecay = A1;
// Decay
int decay_level = 0;
int iDecay = 0;

// Set the input for the potentiometer Attack Time to analog pin 3
const int potAttackTime = A3;
// Attack Time
int AttackTime_level = 0;
int iAttackTime = 0;

// Software Version Information
String sver = "22-12";

void loop() {

  // Audio Hook
  audioHook();

}

getKeyboard.ino

// getKeyboard
// setupKeyboard
void setupKeyboard() {

  // Initialize the button pin as an input
  pinMode(iKeyboard1, INPUT_PULLUP);
  pinMode(iKeyboard2, INPUT_PULLUP);
  pinMode(iKeyboard3, INPUT_PULLUP);
  pinMode(iKeyboard4, INPUT_PULLUP);
  pinMode(iKeyboard5, INPUT_PULLUP);
  pinMode(iKeyboard6, INPUT_PULLUP);
  pinMode(iKeyboard7, INPUT_PULLUP);
  pinMode(iKeyboard8, INPUT_PULLUP);
  pinMode(iKeyboard10, INPUT_PULLUP);
  pinMode(iKeyboard11, INPUT_PULLUP);
  pinMode(iKeyboard12, INPUT_PULLUP);
  pinMode(iKeyboard13, INPUT_PULLUP);

}
// isKeyboard
void isKeyboard() {

  // Choose envelope levels
  // attack_level
  iAttack = mozziAnalogRead( potAttack );
  attack_level = map( iAttack, 0, 1023, 100, 400);
  // Attack Level
  envelope1.setAttackLevel( attack_level );
  // decay_level
  iDecay = mozziAnalogRead( potDecay );
  decay_level = map( iDecay, 0, 1023, 50, 255);
  // Decay Level
  envelope1.setDecayLevel( decay_level );
  // AttackTime_level
  iAttackTime = mozziAnalogRead( potAttackTime );
  AttackTime_level = map( iAttackTime, 0, 1023, 0, 900);
  // Attack Time Level
  envelope1.setAttackTime( AttackTime_level );

  // Read the state of the button value 1
  if ( digitalRead(iKeyboard1) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 1
    iB1 = iB1 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aSin1.setFreq(iNoteA);

  }
  else
  {

    iB1 = iB1 - 1;

  }

  // Read the state of the button value 2
  if ( digitalRead(iKeyboard2) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 2
    iB2 = iB2 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aSin1.setFreq(iNoteAS);

  }
  else
  {

    iB2 = iB2 - 1;

  }

  // Read the state of the button value 3
  if ( digitalRead(iKeyboard3) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 3
    iB3 = iB3 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aSin1.setFreq(iNoteB);

  }
  else
  {

    iB3 = iB3 - 1;

  }

  // Read the state of the button value 4
  if ( digitalRead(iKeyboard4) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 4
    iB4 = iB4 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aSin1.setFreq(iNoteC);

  }
  else
  {

    iB4 = iB4 - 1;

  }

  // Read the state of the button value 5
  if ( digitalRead(iKeyboard5) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 5
    iB5 = iB5 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aSin1.setFreq(iNoteCS);

  }
  else
  {

    iB5 = iB5 - 1;

  }

  // Read the state of the button value 6
  if ( digitalRead(iKeyboard6) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 6
    iB6 = iB6 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aSin1.setFreq(iNoteD);

  }
  else
  {

    iB6 = iB6 - 1;

  }

  // Read the state of the button value 7
  if ( digitalRead(iKeyboard7) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 7
    iB7 = iB7 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aSin1.setFreq(iNoteDS);

  }
  else
  {

    iB7 = iB7 - 1;

  }

  // Read the state of the button value 8
  if ( digitalRead(iKeyboard8) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 8
    iB8 = iB8 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aSin1.setFreq(iNoteE);

  }
  else
  {

    iB8 = iB8 - 1;

  }

  // Read the state of the button value 10
  if ( digitalRead(iKeyboard10) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 10
    iB10 = iB10 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aSin1.setFreq(iNoteF);

  }
  else
  {

    iB10 = iB10 - 1;

  }

  // Read the state of the button value 11
  if ( digitalRead(iKeyboard11) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 11
    iB11 = iB11 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aSin1.setFreq(iNoteFS);

  }
  else
  {

    iB11 = iB11 - 1;

  }

  // Read the state of the button value 12
  if ( digitalRead(iKeyboard12) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 12
    iB12 = iB12 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aSin1.setFreq(iNoteG);

  }
  else
  {

    iB12 = iB12 - 1;

  }

  // Read the state of the button value 13
  if ( digitalRead(iKeyboard13) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 13
    iB13 = iB13 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aSin1.setFreq(iNoteGS);

  }
  else
  {

    iB13 = iB13 - 1;

  }

}

getMozzi.ino

// Mozzi
// Update Control
void updateControl(){

  // Frequency
  isPitches();

  // Keyboard
  isKeyboard();

}
// Update Audio
int updateAudio()
{

  // Update Audio
  // ADSR declaration/definition
  envelope1.update();
  // >>8 for AUDIO_MODE STANDARD
  return (int) (envelope1.next() * aSin1.next())>>8;

}

getPitches.ino

// Pitches
// isPitches
void isPitches(){

  // Frequency
  // Value is 0-1023
  iFreg = mozziAnalogRead(potFreq);
  iFreg = map(iFreg, 0, 1023, 2, 6);

  // Range Frequency Note Low => High
  switch ( iFreg ) {
    case 1:
      // NOTE A1
      iNoteA = NOTE_A1;
      iNoteAS = NOTE_AS1;
      iNoteB = NOTE_B1;
      iNoteC = NOTE_C2;
      iNoteCS = NOTE_CS2;
      iNoteD = NOTE_D2;
      iNoteDS = NOTE_DS2;
      iNoteE = NOTE_E2;
      iNoteF = NOTE_F2;
      iNoteFS = NOTE_FS2;
      iNoteG = NOTE_G2;
      iNoteGS = NOTE_GS2;
      break;
    case 2:
      // NOTE A2
      iNoteA = NOTE_A2;
      iNoteAS = NOTE_AS2;
      iNoteB = NOTE_B2;
      iNoteC = NOTE_C3;
      iNoteCS = NOTE_CS3;
      iNoteD = NOTE_D3;
      iNoteDS = NOTE_DS3;
      iNoteE = NOTE_E3;
      iNoteF = NOTE_F3;
      iNoteFS = NOTE_FS3;
      iNoteG = NOTE_G3;
      iNoteGS = NOTE_GS3;
      break;
    case 3:
      // NOTE A3
      iNoteA = NOTE_A3;
      iNoteAS = NOTE_AS3;
      iNoteB = NOTE_B3;
      iNoteC = NOTE_C4;
      iNoteD = NOTE_D4;
      iNoteDS = NOTE_DS4;
      iNoteE = NOTE_E4;
      iNoteF = NOTE_F4;
      iNoteFS = NOTE_FS4;
      iNoteG = NOTE_G4;
      iNoteGS = NOTE_GS4;
      break;
    case 4:
      // NOTE A4
      iNoteA = NOTE_A4;
      iNoteAS = NOTE_AS4;
      iNoteB = NOTE_B4;
      iNoteC = NOTE_C5;
      iNoteCS = NOTE_CS5;
      iNoteD = NOTE_D5;
      iNoteE = NOTE_E5;
      iNoteF = NOTE_F5;
      iNoteFS = NOTE_FS5;
      iNoteG = NOTE_G5;
      iNoteGS = NOTE_GS5;
      break;
    case 5:
      // NOTE A5
      iNoteA = NOTE_A5;
      iNoteAS = NOTE_AS5;
      iNoteB = NOTE_B5;
      iNoteC = NOTE_C6;
      iNoteCS = NOTE_CS6;
      iNoteD = NOTE_D6;
      iNoteDS = NOTE_DS6;
      iNoteE = NOTE_E6;
      iNoteF = NOTE_F6;
      iNoteFS = NOTE_FS6;
      iNoteG = NOTE_G6;
      iNoteGS = NOTE_GS6;
      break;
    case 6:
      // NOTE A6
      iNoteA = NOTE_A6;
      iNoteAS = NOTE_AS6;
      iNoteB = NOTE_B6;
      iNoteC = NOTE_C7;
      iNoteCS = NOTE_CS7;
      iNoteD = NOTE_D7;
      iNoteDS = NOTE_DS7;
      iNoteE = NOTE_E7;
      iNoteF = NOTE_F7;
      iNoteFS = NOTE_FS7;
      iNoteG = NOTE_G7;
      iNoteGS = NOTE_GS7;
      break;
  }

}

pitches.h

/*****************************************************************
 * Pitches NOTE_B0 <=> NOTE_DS8 - NOTE_A4 is "A" measured at 440Hz
 *****************************************************************/

#define NOTE_B0  31
#define NOTE_C1  33
#define NOTE_CS1  35
#define NOTE_D1  37
#define NOTE_DS1  39
#define NOTE_E1  41
#define NOTE_F1  44
#define NOTE_FS1  46
#define NOTE_G1  49
#define NOTE_GS1  52
#define NOTE_A1  55
#define NOTE_AS1  58
#define NOTE_B1  62
#define NOTE_C2  65
#define NOTE_CS2  69
#define NOTE_D2  73
#define NOTE_DS2  78
#define NOTE_E2  82
#define NOTE_F2  87
#define NOTE_FS2  93
#define NOTE_G2  98
#define NOTE_GS2  104
#define NOTE_A2  110
#define NOTE_AS2  117
#define NOTE_B2  123
#define NOTE_C3  131
#define NOTE_CS3  139
#define NOTE_D3  147
#define NOTE_DS3  156
#define NOTE_E3  165
#define NOTE_F3  175
#define NOTE_FS3 185
#define NOTE_G3  196
#define NOTE_GS3  208
#define NOTE_A3  220
#define NOTE_AS3  233
#define NOTE_B3  247
#define NOTE_C4  262
#define NOTE_CS4  277
#define NOTE_D4  294
#define NOTE_DS4 311
#define NOTE_E4  330
#define NOTE_F4  349
#define NOTE_FS4  370
#define NOTE_G4  392
#define NOTE_GS4  415
#define NOTE_A4  440
#define NOTE_AS4  466
#define NOTE_B4  494
#define NOTE_C5  523
#define NOTE_CS5  554
#define NOTE_D5  587
#define NOTE_DS5  622
#define NOTE_E5  659
#define NOTE_F5  698
#define NOTE_FS5  740
#define NOTE_G5  784
#define NOTE_GS5  831
#define NOTE_A5  880
#define NOTE_AS5  932
#define NOTE_B5  988
#define NOTE_C6  1047
#define NOTE_CS6  1109
#define NOTE_D6  1175
#define NOTE_DS6  1245
#define NOTE_E6  1319
#define NOTE_F6  1397
#define NOTE_FS6  1480
#define NOTE_G6  1568
#define NOTE_GS6  1661
#define NOTE_A6  1760
#define NOTE_AS6  1865
#define NOTE_B6  1976
#define NOTE_C7  2093
#define NOTE_CS7  2217
#define NOTE_D7  2349
#define NOTE_DS7  2489
#define NOTE_E7  2637
#define NOTE_F7  2794
#define NOTE_FS7  2960
#define NOTE_G7  3136
#define NOTE_GS7  3322
#define NOTE_A7  3520
#define NOTE_AS7  3729
#define NOTE_B7  3951
#define NOTE_C8  4186
#define NOTE_CS8  4435
#define NOTE_D8  4699
#define NOTE_DS8  4978

setup.ino

// Setup
void setup() {

  // Setup Keyboard
  setupKeyboard();

  // Mozzi Start
  startMozzi( CONTROL_RATE );
  // Sets Attack and Decay Levels; assumes Sustain, Decay, and Idle times
  envelope1.setADLevels(200,200);
  // Sets Decay time in milliseconds
  envelope1.setDecayTime(200);
  // Sustain Time setting for envelope1
  envelope1.setSustainTime(52500);

}

——

People can contact us: https://www.donluc.com/?page_id=1927

Technology Experience

  • Single-Board Microcontrollers (PIC, Arduino, Raspberry Pi,Espressif, etc…)
  • IoT
  • Robotics
  • Camera and Video Capture Receiver Stationary, Wheel/Tank and Underwater Vehicle
  • Unmanned Vehicles Terrestrial and Marine
  • Research & Development (R & D)

Instructor and E-Mentor

  • IoT
  • PIC Microcontrollers
  • Arduino
  • Raspberry Pi
  • Espressif
  • Robotics

Follow Us

J. Luc Paquin – Curriculum Vitae – 2022 English & Español
https://www.jlpconsultants.com/luc/

Web: https://www.donluc.com/
Web: https://www.jlpconsultants.com/
Facebook: https://www.facebook.com/neosteam.labs.9/
YouTube: https://www.youtube.com/channel/UC5eRjrGn1CqkkGfZy0jxEdA
Twitter: https://twitter.com/labs_steam
Pinterest: https://www.pinterest.com/NeoSteamLabs/
Instagram: https://www.instagram.com/neosteamlabs/

Don Luc

Project #22: Synthesizer – 4 Stages – Mk11

——

#DonLucElectronics #DonLuc #Synthesizer #Mozzi #Keyboard #ADSREnvelope #Arduino #SparkFunRedBoard #Project #Fritzing #Programming #Electronics #Microcontrollers #Consultant

——

4 Stages

——

4 Stages

——

4 Stages

——

4 Stages of an ADSR Envelope

An ADSR envelope features these four stages.

  • 1 Attack: The attack phase begins the moment a key is pressed. This phase determines how quickly a sound reaches full volume before entering the decay phase. On an analog synthesizer, this phase is typically instantaneous. Some modern synthesizers allow for the attack time to be delayed.
  • 2 Decay: The decay phase determines the length of the drop from the peak level to the sustain level of a sound. The decay time can often be altered to change the overall sound. For instance, a short attack and a long decay will produce a sound that reaches maximum amplitude quickly and falls slowly to the sustain level.
  • 3 Sustain: The sustain phase does not specify a length of time. Instead, it determines the volume of a sound for the entire hold time between the decay and release phases.
  • 4 Release: The final phase determines the speed at which a sound ends from the moment you release the key. Depending on the desired sound, the release time can be short or long.

DL2208Mk04

1 x SparkFun RedBoard
7 x Momentary Button – Panel Mount (Blue)
5 x Momentary Button – Panel Mount (Black)
12 x 10K Ohm Resistor
5 x 10k Ohm Slide Linear Taper Pot – X-Large
5 x Slide Potentiometer Knob – X-Large
1 x Perfboard 13.5 cm x 11 cm
1 x SparkFun Solderable Breadboard
1 x Audio Jack 3.5mm
1 x SparkFun Audio Jack Breakout
1 x SparkFun ProtoShield
1 x Insignia Speakers
1 x SparkFun Cerberus USB Cable

SparkFun RedBoard

LP0 – Analog A0 – Blue
LP1 – Analog A1 – Green
LP2 – Analog A2 – Grey
LP3 – Analog A3 – Yellow
LP4 – Analog A4 – Purple
KY1 – 1
KY2 – 2
KY3 – 3
KY4 – 4
KY5 – 5
KY6 – 6
KY7 – 7
KY8 – 8
SPK – 9
KY10 – 10
KY11 – 11
KY12 – 12
KY13 – 13
VIN – +5V
GND – GND

DL2208Mk04p.ino

/* ***** Don Luc Electronics © *****
Software Version Information
Project #22: Synthesizer - 4 Stages - Mk11
22-11
DL2208Mk04p.ino
1 x SparkFun RedBoard
7 x Momentary Button - Panel Mount (Blue)
5 x Momentary Button - Panel Mount (Black)
12 x 1K Ohm Resistor
5 x 10k Ohm Slide Linear Taper Pot - X-Large
5 x Slide Potentiometer Knob - X-Large
1 x Perfboard 13.5 cm x 11 cm
1 x SparkFun Solderable Breadboard
1 x Audio Jack 3.5mm
1 x SparkFun Audio Jack Breakout
1 x SparkFun ProtoShield
1 x Insignia Speakers
1 x SparkFun Cerberus USB Cable
*/

// Include the Library Code
// Pitches
#include "pitches.h"
// Mozzi
#include <MozziGuts.h>
// Oscillator
#include <Oscil.h>
// Sine Wave Table For Oscillator
#include <tables/sin2048_int8.h>
// ADSR envelope generator
#include <ADSR.h>

// Simple Keyboard
// Minimum reading of the button that generates a note
const int iKeyboard1 = 1;
const int iKeyboard2 = 2;
const int iKeyboard3 = 3;
const int iKeyboard4 = 4;
const int iKeyboard5 = 5;
const int iKeyboard6 = 6;
const int iKeyboard7 = 7;
const int iKeyboard8 = 8;
const int iKeyboard10 = 10;
const int iKeyboard11 = 11;
const int iKeyboard12 = 12;
const int iKeyboard13 = 13;
// Button is pressed
int iB1 = 1;
int iB2 = 1;
int iB3 = 1;
int iB4 = 1;
int iB5 = 1;
int iB6 = 1;
int iB7 = 1;
int iB8 = 1;
int iB10 = 1;
int iB11 = 1;
int iB12 = 1;
int iB13 = 1;

// Set the input for the potentiometer for Frequency to analog pin 2
const int potFreq = A2;
int iFreg = 1;
int iNoteA = 0;
int iNoteAS = 0;
int iNoteB = 0;
int iNoteC = 0;
int iNoteCS = 0;
int iNoteD = 0;
int iNoteDS = 0;
int iNoteE = 0;
int iNoteF = 0;
int iNoteFS = 0;
int iNoteG = 0;
int iNoteGS = 0;

// Potentiometer
int iPot3 = A3;
int iPot4 = A4;

//Oscillator Functions declared for output envelope 1
// Sine Wave
Oscil <2048, AUDIO_RATE> aSin1(SIN2048_DATA);

// ADSR declaration/definition
// Comment out to use control rate of 128
#define CONTROL_RATE 128
ADSR <CONTROL_RATE, CONTROL_RATE> envelope1;

// Set the input for the potentiometer Attack to analog pin 1
const int potAttack = A0;
// Attack
int attack_level = 0;
int iAttack = 0;

// Set the input for the potentiometer for Decay to analog pin 2
const int potDecay = A1;
// Decay
int decay_level = 0;
int iDecay = 0;

// Software Version Information
String sver = "22-11";

void loop() {

  // Audio Hook
  audioHook();

}

getKeyboard.ino

// getKeyboard
// setupKeyboard
void setupKeyboard() {

  // Initialize the button pin as an input
  pinMode(iKeyboard1, INPUT_PULLUP);
  pinMode(iKeyboard2, INPUT_PULLUP);
  pinMode(iKeyboard3, INPUT_PULLUP);
  pinMode(iKeyboard4, INPUT_PULLUP);
  pinMode(iKeyboard5, INPUT_PULLUP);
  pinMode(iKeyboard6, INPUT_PULLUP);
  pinMode(iKeyboard7, INPUT_PULLUP);
  pinMode(iKeyboard8, INPUT_PULLUP);
  pinMode(iKeyboard10, INPUT_PULLUP);
  pinMode(iKeyboard11, INPUT_PULLUP);
  pinMode(iKeyboard12, INPUT_PULLUP);
  pinMode(iKeyboard13, INPUT_PULLUP);

}
// isKeyboard
void isKeyboard() {

  // Choose envelope levels
  // attack_level
  iAttack = mozziAnalogRead( potAttack );
  attack_level = map( iAttack, 0, 1023, 100, 400);
  // Attack Level
  envelope1.setAttackLevel( attack_level );
  // decay_level
  iDecay = mozziAnalogRead( potDecay );
  decay_level = map( iDecay, 0, 1023, 50, 255);
  // Decay Level
  envelope1.setDecayLevel( decay_level );

  // Read the state of the button value 1
  if ( digitalRead(iKeyboard1) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 1
    iB1 = iB1 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aSin1.setFreq(iNoteA);

  }
  else
  {

    iB1 = iB1 - 1;

  }

  // Read the state of the button value 2
  if ( digitalRead(iKeyboard2) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 2
    iB2 = iB2 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aSin1.setFreq(iNoteAS);

  }
  else
  {

    iB2 = iB2 - 1;

  }

  // Read the state of the button value 3
  if ( digitalRead(iKeyboard3) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 3
    iB3 = iB3 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aSin1.setFreq(iNoteB);

  }
  else
  {

    iB3 = iB3 - 1;

  }

  // Read the state of the button value 4
  if ( digitalRead(iKeyboard4) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 4
    iB4 = iB4 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aSin1.setFreq(iNoteC);

  }
  else
  {

    iB4 = iB4 - 1;

  }

  // Read the state of the button value 5
  if ( digitalRead(iKeyboard5) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 5
    iB5 = iB5 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aSin1.setFreq(iNoteCS);

  }
  else
  {

    iB5 = iB5 - 1;

  }

  // Read the state of the button value 6
  if ( digitalRead(iKeyboard6) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 6
    iB6 = iB6 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aSin1.setFreq(iNoteD);

  }
  else
  {

    iB6 = iB6 - 1;

  }

  // Read the state of the button value 7
  if ( digitalRead(iKeyboard7) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 7
    iB7 = iB7 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aSin1.setFreq(iNoteDS);

  }
  else
  {

    iB7 = iB7 - 1;

  }

  // Read the state of the button value 8
  if ( digitalRead(iKeyboard8) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 8
    iB8 = iB8 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aSin1.setFreq(iNoteE);

  }
  else
  {

    iB8 = iB8 - 1;

  }

  // Read the state of the button value 10
  if ( digitalRead(iKeyboard10) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 10
    iB10 = iB10 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aSin1.setFreq(iNoteF);

  }
  else
  {

    iB10 = iB10 - 1;

  }

  // Read the state of the button value 11
  if ( digitalRead(iKeyboard11) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 11
    iB11 = iB11 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aSin1.setFreq(iNoteFS);

  }
  else
  {

    iB11 = iB11 - 1;

  }

  // Read the state of the button value 12
  if ( digitalRead(iKeyboard12) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 12
    iB12 = iB12 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aSin1.setFreq(iNoteG);

  }
  else
  {

    iB12 = iB12 - 1;

  }

  // Read the state of the button value 13
  if ( digitalRead(iKeyboard13) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 13
    iB13 = iB13 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aSin1.setFreq(iNoteGS);

  }
  else
  {

    iB13 = iB13 - 1;

  }

}

getMozzi.ino

// Mozzi
// Update Control
void updateControl(){

  // Frequency
  isPitches();

  // Keyboard
  isKeyboard();

}
// Update Audio
int updateAudio()
{

  // Update Audio
  // ADSR declaration/definition
  envelope1.update();
  // >>8 for AUDIO_MODE STANDARD
  return (int) (envelope1.next() * aSin1.next())>>8;

}

getPitches.ino

// Pitches
// isPitches
void isPitches(){

  // Frequency
  // Value is 0-1023
  iFreg = mozziAnalogRead(potFreq);
  iFreg = map(iFreg, 0, 1023, 2, 6);

  // Range Frequency Note Low => High
  switch ( iFreg ) {
    case 1:
      // NOTE A1
      iNoteA = NOTE_A1;
      iNoteAS = NOTE_AS1;
      iNoteB = NOTE_B1;
      iNoteC = NOTE_C2;
      iNoteCS = NOTE_CS2;
      iNoteD = NOTE_D2;
      iNoteDS = NOTE_DS2;
      iNoteE = NOTE_E2;
      iNoteF = NOTE_F2;
      iNoteFS = NOTE_FS2;
      iNoteG = NOTE_G2;
      iNoteGS = NOTE_GS2;
      break;
    case 2:
      // NOTE A2
      iNoteA = NOTE_A2;
      iNoteAS = NOTE_AS2;
      iNoteB = NOTE_B2;
      iNoteC = NOTE_C3;
      iNoteCS = NOTE_CS3;
      iNoteD = NOTE_D3;
      iNoteDS = NOTE_DS3;
      iNoteE = NOTE_E3;
      iNoteF = NOTE_F3;
      iNoteFS = NOTE_FS3;
      iNoteG = NOTE_G3;
      iNoteGS = NOTE_GS3;
      break;
    case 3:
      // NOTE A3
      iNoteA = NOTE_A3;
      iNoteAS = NOTE_AS3;
      iNoteB = NOTE_B3;
      iNoteC = NOTE_C4;
      iNoteD = NOTE_D4;
      iNoteDS = NOTE_DS4;
      iNoteE = NOTE_E4;
      iNoteF = NOTE_F4;
      iNoteFS = NOTE_FS4;
      iNoteG = NOTE_G4;
      iNoteGS = NOTE_GS4;
      break;
    case 4:
      // NOTE A4
      iNoteA = NOTE_A4;
      iNoteAS = NOTE_AS4;
      iNoteB = NOTE_B4;
      iNoteC = NOTE_C5;
      iNoteCS = NOTE_CS5;
      iNoteD = NOTE_D5;
      iNoteE = NOTE_E5;
      iNoteF = NOTE_F5;
      iNoteFS = NOTE_FS5;
      iNoteG = NOTE_G5;
      iNoteGS = NOTE_GS5;
      break;
    case 5:
      // NOTE A5
      iNoteA = NOTE_A5;
      iNoteAS = NOTE_AS5;
      iNoteB = NOTE_B5;
      iNoteC = NOTE_C6;
      iNoteCS = NOTE_CS6;
      iNoteD = NOTE_D6;
      iNoteDS = NOTE_DS6;
      iNoteE = NOTE_E6;
      iNoteF = NOTE_F6;
      iNoteFS = NOTE_FS6;
      iNoteG = NOTE_G6;
      iNoteGS = NOTE_GS6;
      break;
    case 6:
      // NOTE A6
      iNoteA = NOTE_A6;
      iNoteAS = NOTE_AS6;
      iNoteB = NOTE_B6;
      iNoteC = NOTE_C7;
      iNoteCS = NOTE_CS7;
      iNoteD = NOTE_D7;
      iNoteDS = NOTE_DS7;
      iNoteE = NOTE_E7;
      iNoteF = NOTE_F7;
      iNoteFS = NOTE_FS7;
      iNoteG = NOTE_G7;
      iNoteGS = NOTE_GS7;
      break;
  }

}

pitches.h

/*****************************************************************
 * Pitches NOTE_B0 <=> NOTE_DS8 - NOTE_A4 is "A" measured at 440Hz
 *****************************************************************/

#define NOTE_B0  31
#define NOTE_C1  33
#define NOTE_CS1  35
#define NOTE_D1  37
#define NOTE_DS1  39
#define NOTE_E1  41
#define NOTE_F1  44
#define NOTE_FS1  46
#define NOTE_G1  49
#define NOTE_GS1  52
#define NOTE_A1  55
#define NOTE_AS1  58
#define NOTE_B1  62
#define NOTE_C2  65
#define NOTE_CS2  69
#define NOTE_D2  73
#define NOTE_DS2  78
#define NOTE_E2  82
#define NOTE_F2  87
#define NOTE_FS2  93
#define NOTE_G2  98
#define NOTE_GS2  104
#define NOTE_A2  110
#define NOTE_AS2  117
#define NOTE_B2  123
#define NOTE_C3  131
#define NOTE_CS3  139
#define NOTE_D3  147
#define NOTE_DS3  156
#define NOTE_E3  165
#define NOTE_F3  175
#define NOTE_FS3 185
#define NOTE_G3  196
#define NOTE_GS3  208
#define NOTE_A3  220
#define NOTE_AS3  233
#define NOTE_B3  247
#define NOTE_C4  262
#define NOTE_CS4  277
#define NOTE_D4  294
#define NOTE_DS4 311
#define NOTE_E4  330
#define NOTE_F4  349
#define NOTE_FS4  370
#define NOTE_G4  392
#define NOTE_GS4  415
#define NOTE_A4  440
#define NOTE_AS4  466
#define NOTE_B4  494
#define NOTE_C5  523
#define NOTE_CS5  554
#define NOTE_D5  587
#define NOTE_DS5  622
#define NOTE_E5  659
#define NOTE_F5  698
#define NOTE_FS5  740
#define NOTE_G5  784
#define NOTE_GS5  831
#define NOTE_A5  880
#define NOTE_AS5  932
#define NOTE_B5  988
#define NOTE_C6  1047
#define NOTE_CS6  1109
#define NOTE_D6  1175
#define NOTE_DS6  1245
#define NOTE_E6  1319
#define NOTE_F6  1397
#define NOTE_FS6  1480
#define NOTE_G6  1568
#define NOTE_GS6  1661
#define NOTE_A6  1760
#define NOTE_AS6  1865
#define NOTE_B6  1976
#define NOTE_C7  2093
#define NOTE_CS7  2217
#define NOTE_D7  2349
#define NOTE_DS7  2489
#define NOTE_E7  2637
#define NOTE_F7  2794
#define NOTE_FS7  2960
#define NOTE_G7  3136
#define NOTE_GS7  3322
#define NOTE_A7  3520
#define NOTE_AS7  3729
#define NOTE_B7  3951
#define NOTE_C8  4186
#define NOTE_CS8  4435
#define NOTE_D8  4699
#define NOTE_DS8  4978

setup.ino

// Setup
void setup() {

  // Setup Keyboard
  setupKeyboard();

  // Mozzi Start
  startMozzi( CONTROL_RATE );
  // Sets Attack and Decay Levels; assumes Sustain, Decay, and Idle times
  envelope1.setADLevels(200,200);
  // Sets Decay time in milliseconds
  envelope1.setDecayTime(200);
  // Sustain Time setting for envelope1
  envelope1.setSustainTime(52500);

}

——

People can contact us: https://www.donluc.com/?page_id=1927

Technology Experience

  • Single-Board Microcontrollers (PIC, Arduino, Raspberry Pi,Espressif, etc…)
  • IoT
  • Robotics
  • Camera and Video Capture Receiver Stationary, Wheel/Tank and Underwater Vehicle
  • Unmanned Vehicles Terrestrial and Marine
  • Research & Development (R & D)

Instructor and E-Mentor

  • IoT
  • PIC Microcontrollers
  • Arduino
  • Raspberry Pi
  • Espressif
  • Robotics

Follow Us

J. Luc Paquin – Curriculum Vitae – 2022 English & Español
https://www.jlpconsultants.com/luc/

Web: https://www.donluc.com/
Web: https://www.jlpconsultants.com/
Facebook: https://www.facebook.com/neosteam.labs.9/
YouTube: https://www.youtube.com/channel/UC5eRjrGn1CqkkGfZy0jxEdA
Twitter: https://twitter.com/labs_steam
Pinterest: https://www.pinterest.com/NeoSteamLabs/
Instagram: https://www.instagram.com/neosteamlabs/

Don Luc

Project #22: Synthesizer – ADSR Envelope – Mk10

——

#DonLucElectronics #DonLuc #Synthesizer #Mozzi #Keyboard #ADSREnvelope #Arduino #SparkFunRedBoard #Project #Fritzing #Programming #Electronics #Microcontrollers #Consultant

——

ADSR Envelope

——

ADSR Envelope

——

ADSR Envelope

——

What Is an Envelope in Music?

An envelope is a term used to describe the evolution of a sound in a piece of music. Envelopes are fed through an envelope generator, the component within an analog synthesizer that signals when and how a sound should change. The envelope defines the trajectory and modulation of a sound, while the envelope generator controls the behavior of the envelope.

What Is an ADSR Envelope?

An ADSR envelope is a type of envelope control mechanism commonly found in the synthesizer and samplers used in electronic music. ADSR stands for the envelope’s four stages of modulation: attack, decay, sustain, and release. These stages control the level of the sound from the moment you press a key or advance a music sequencer.

In sound design, ADSR envelopes are typically used to control the loudness of a sound. ADSR envelopes typically produce a sound that takes the shape of a waveform rising in the attack stage, slightly declining during the decay stage, plateauing during the sustain stage, and finally falling at the return stage.

DL2208Mk03

1 x SparkFun RedBoard
7 x Momentary Button – Panel Mount (Blue)
5 x Momentary Button – Panel Mount (Black)
12 x 10K Ohm Resistor
5 x 10k Ohm Slide Linear Taper Pot – X-Large
5 x Slide Potentiometer Knob – X-Large
1 x Perfboard 13.5 cm x 11 cm
1 x SparkFun Solderable Breadboard
1 x Audio Jack 3.5mm
1 x SparkFun Audio Jack Breakout
1 x SparkFun ProtoShield
1 x Insignia Speakers
1 x SparkFun Cerberus USB Cable

SparkFun RedBoard

LP0 – Analog A0 – Blue
LP1 – Analog A1 – Green
LP2 – Analog A2 – Grey
LP3 – Analog A3 – Yellow
LP4 – Analog A4 – Purple
KY1 – 1
KY2 – 2
KY3 – 3
KY4 – 4
KY5 – 5
KY6 – 6
KY7 – 7
KY8 – 8
SPK – 9
KY10 – 10
KY11 – 11
KY12 – 12
KY13 – 13
VIN – +5V
GND – GND

——

DL2208Mk03p.ino

/* ***** Don Luc Electronics © *****
Software Version Information
Project #22: Synthesizer - ADSR Envelope - Mk10
22-10
DL2208Mk03p.ino
1 x SparkFun RedBoard
7 x Momentary Button - Panel Mount (Blue)
5 x Momentary Button - Panel Mount (Black)
12 x 1K Ohm Resistor
5 x 10k Ohm Slide Linear Taper Pot - X-Large
5 x Slide Potentiometer Knob - X-Large
1 x Perfboard 13.5 cm x 11 cm
1 x SparkFun Solderable Breadboard
1 x Audio Jack 3.5mm
1 x SparkFun Audio Jack Breakout
1 x SparkFun ProtoShield
1 x Insignia Speakers
1 x SparkFun Cerberus USB Cable
*/

// Include the Library Code
// Pitches
#include "pitches.h"
// Mozzi
#include <MozziGuts.h>
// Oscillator
#include <Oscil.h>
// Sine Wave Table For Oscillator
#include <tables/sin2048_int8.h>
// ADSR envelope generator
#include <ADSR.h>

// Simple Keyboard
// Minimum reading of the button that generates a note
const int iKeyboard1 = 1;
const int iKeyboard2 = 2;
const int iKeyboard3 = 3;
const int iKeyboard4 = 4;
const int iKeyboard5 = 5;
const int iKeyboard6 = 6;
const int iKeyboard7 = 7;
const int iKeyboard8 = 8;
const int iKeyboard10 = 10;
const int iKeyboard11 = 11;
const int iKeyboard12 = 12;
const int iKeyboard13 = 13;
// Button is pressed
int iB1 = 1;
int iB2 = 1;
int iB3 = 1;
int iB4 = 1;
int iB5 = 1;
int iB6 = 1;
int iB7 = 1;
int iB8 = 1;
int iB10 = 1;
int iB11 = 1;
int iB12 = 1;
int iB13 = 1;

// Set the input for the potentiometer for Frequency to analog pin 3
//const int potFreq = A3;
int iFreg = 1;
int iNoteA = 0;
int iNoteAS = 0;
int iNoteB = 0;
int iNoteC = 0;
int iNoteCS = 0;
int iNoteD = 0;
int iNoteDS = 0;
int iNoteE = 0;
int iNoteF = 0;
int iNoteFS = 0;
int iNoteG = 0;
int iNoteGS = 0;

// Potentiometer
int iPot2 = A2;
int iPot3 = A3;
int iPot4 = A4;

//Oscillator Functions declared for output envelope 1
// Sine Wave
Oscil <2048, AUDIO_RATE> aSin1(SIN2048_DATA);

// ADSR declaration/definition
// Comment out to use control rate of 128
#define CONTROL_RATE 128
ADSR <CONTROL_RATE, CONTROL_RATE> envelope1;

// Set the input for the potentiometer Attack to analog pin 1
const int potAttack = A0;
// Attack
int attack_level = 0;
int iAttack = 0;

// Set the input for the potentiometer for Decay to analog pin 2
const int potDecay = A1;
// Decay
int decay_level = 0;
int iDecay = 0;

// Software Version Information
String sver = "22-10";

void loop() {

  // Audio Hook
  audioHook();

}

getKeyboard.ino

// getKeyboard
// setupKeyboard
void setupKeyboard() {

  // Initialize the button pin as an input
  pinMode(iKeyboard1, INPUT_PULLUP);
  pinMode(iKeyboard2, INPUT_PULLUP);
  pinMode(iKeyboard3, INPUT_PULLUP);
  pinMode(iKeyboard4, INPUT_PULLUP);
  pinMode(iKeyboard5, INPUT_PULLUP);
  pinMode(iKeyboard6, INPUT_PULLUP);
  pinMode(iKeyboard7, INPUT_PULLUP);
  pinMode(iKeyboard8, INPUT_PULLUP);
  pinMode(iKeyboard10, INPUT_PULLUP);
  pinMode(iKeyboard11, INPUT_PULLUP);
  pinMode(iKeyboard12, INPUT_PULLUP);
  pinMode(iKeyboard13, INPUT_PULLUP);

}
// isKeyboard
void isKeyboard() {

  // Choose envelope levels
  // attack_level
  iAttack = mozziAnalogRead( potAttack );
  attack_level = map( iAttack, 0, 1023, 0, 255);
  // decay_level
  iDecay = mozziAnalogRead( potDecay );
  decay_level = map( iDecay, 0, 1023, 0, 255);
  // set AD Levels
  envelope1.setADLevels(attack_level,decay_level);

  // Read the state of the button value 1
  if ( digitalRead(iKeyboard1) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 1
    iB1 = iB1 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aSin1.setFreq(iNoteA);

  }
  else
  {

    iB1 = iB1 - 1;

  }

  // Read the state of the button value 2
  if ( digitalRead(iKeyboard2) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 2
    iB2 = iB2 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aSin1.setFreq(iNoteAS);

  }
  else
  {

    iB2 = iB2 - 1;

  }

  // Read the state of the button value 3
  if ( digitalRead(iKeyboard3) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 3
    iB3 = iB3 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aSin1.setFreq(iNoteB);

  }
  else
  {

    iB3 = iB3 - 1;

  }

  // Read the state of the button value 4
  if ( digitalRead(iKeyboard4) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 4
    iB4 = iB4 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aSin1.setFreq(iNoteC);

  }
  else
  {

    iB4 = iB4 - 1;

  }

  // Read the state of the button value 5
  if ( digitalRead(iKeyboard5) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 5
    iB5 = iB5 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aSin1.setFreq(iNoteCS);

  }
  else
  {

    iB5 = iB5 - 1;

  }

  // Read the state of the button value 6
  if ( digitalRead(iKeyboard6) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 6
    iB6 = iB6 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aSin1.setFreq(iNoteD);

  }
  else
  {

    iB6 = iB6 - 1;

  }

  // Read the state of the button value 7
  if ( digitalRead(iKeyboard7) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 7
    iB7 = iB7 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aSin1.setFreq(iNoteDS);

  }
  else
  {

    iB7 = iB7 - 1;

  }

  // Read the state of the button value 8
  if ( digitalRead(iKeyboard8) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 8
    iB8 = iB8 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aSin1.setFreq(iNoteE);

  }
  else
  {

    iB8 = iB8 - 1;

  }

  // Read the state of the button value 10
  if ( digitalRead(iKeyboard10) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 10
    iB10 = iB10 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aSin1.setFreq(iNoteF);

  }
  else
  {

    iB10 = iB10 - 1;

  }

  // Read the state of the button value 11
  if ( digitalRead(iKeyboard11) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 11
    iB11 = iB11 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aSin1.setFreq(iNoteFS);

  }
  else
  {

    iB11 = iB11 - 1;

  }

  // Read the state of the button value 12
  if ( digitalRead(iKeyboard12) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 12
    iB12 = iB12 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aSin1.setFreq(iNoteG);

  }
  else
  {

    iB12 = iB12 - 1;

  }

  // Read the state of the button value 13
  if ( digitalRead(iKeyboard13) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 13
    iB13 = iB13 + 1;
    // ADSR declaration/definition
    envelope1.noteOn();
    aSin1.setFreq(iNoteGS);

  }
  else
  {

    iB13 = iB13 - 1;

  }

}

getMozzi.ino

// Mozzi
// Update Control
void updateControl(){

  // Frequency
  isPitches();

  // Keyboard
  isKeyboard();

}
// Update Audio
int updateAudio()
{

  // Update Audio
  // ADSR declaration/definition
  envelope1.update();
  // >>8 for AUDIO_MODE STANDARD
  return (int) (envelope1.next() * aSin1.next())>>8;

}

getPitches.ino

// Pitches
// isPitches
void isPitches(){

  // Frequency
  // Value is 0-1023
  //iFreg = mozziAnalogRead(potFreq);
  //iFreg = map(iFreg, 0, 1023, 3, 6);
  iFreg = 5;

  // Range Frequency Note Low => High
  switch ( iFreg ) {
    case 1:
      // NOTE A1
      iNoteA = NOTE_A1;
      iNoteAS = NOTE_AS1;
      iNoteB = NOTE_B1;
      iNoteC = NOTE_C2;
      iNoteCS = NOTE_CS2;
      iNoteD = NOTE_D2;
      iNoteDS = NOTE_DS2;
      iNoteE = NOTE_E2;
      iNoteF = NOTE_F2;
      iNoteFS = NOTE_FS2;
      iNoteG = NOTE_G2;
      iNoteGS = NOTE_GS2;
      break;
    case 2:
      // NOTE A2
      iNoteA = NOTE_A2;
      iNoteAS = NOTE_AS2;
      iNoteB = NOTE_B2;
      iNoteC = NOTE_C3;
      iNoteCS = NOTE_CS3;
      iNoteD = NOTE_D3;
      iNoteDS = NOTE_DS3;
      iNoteE = NOTE_E3;
      iNoteF = NOTE_F3;
      iNoteFS = NOTE_FS3;
      iNoteG = NOTE_G3;
      iNoteGS = NOTE_GS3;
      break;
    case 3:
      // NOTE A3
      iNoteA = NOTE_A3;
      iNoteAS = NOTE_AS3;
      iNoteB = NOTE_B3;
      iNoteC = NOTE_C4;
      iNoteD = NOTE_D4;
      iNoteDS = NOTE_DS4;
      iNoteE = NOTE_E4;
      iNoteF = NOTE_F4;
      iNoteFS = NOTE_FS4;
      iNoteG = NOTE_G4;
      iNoteGS = NOTE_GS4;
      break;
    case 4:
      // NOTE A4
      iNoteA = NOTE_A4;
      iNoteAS = NOTE_AS4;
      iNoteB = NOTE_B4;
      iNoteC = NOTE_C5;
      iNoteCS = NOTE_CS5;
      iNoteD = NOTE_D5;
      iNoteE = NOTE_E5;
      iNoteF = NOTE_F5;
      iNoteFS = NOTE_FS5;
      iNoteG = NOTE_G5;
      iNoteGS = NOTE_GS5;
      break;
    case 5:
      // NOTE A5
      iNoteA = NOTE_A5;
      iNoteAS = NOTE_AS5;
      iNoteB = NOTE_B5;
      iNoteC = NOTE_C6;
      iNoteCS = NOTE_CS6;
      iNoteD = NOTE_D6;
      iNoteDS = NOTE_DS6;
      iNoteE = NOTE_E6;
      iNoteF = NOTE_F6;
      iNoteFS = NOTE_FS6;
      iNoteG = NOTE_G6;
      iNoteGS = NOTE_GS6;
      break;
    case 6:
      // NOTE A6
      iNoteA = NOTE_A6;
      iNoteAS = NOTE_AS6;
      iNoteB = NOTE_B6;
      iNoteC = NOTE_C7;
      iNoteCS = NOTE_CS7;
      iNoteD = NOTE_D7;
      iNoteDS = NOTE_DS7;
      iNoteE = NOTE_E7;
      iNoteF = NOTE_F7;
      iNoteFS = NOTE_FS7;
      iNoteG = NOTE_G7;
      iNoteGS = NOTE_GS7;
      break;
  }

}

pitches.h

/*****************************************************************
 * Pitches NOTE_B0 <=> NOTE_DS8 - NOTE_A4 is "A" measured at 440Hz
 *****************************************************************/

#define NOTE_B0  31
#define NOTE_C1  33
#define NOTE_CS1  35
#define NOTE_D1  37
#define NOTE_DS1  39
#define NOTE_E1  41
#define NOTE_F1  44
#define NOTE_FS1  46
#define NOTE_G1  49
#define NOTE_GS1  52
#define NOTE_A1  55
#define NOTE_AS1  58
#define NOTE_B1  62
#define NOTE_C2  65
#define NOTE_CS2  69
#define NOTE_D2  73
#define NOTE_DS2  78
#define NOTE_E2  82
#define NOTE_F2  87
#define NOTE_FS2  93
#define NOTE_G2  98
#define NOTE_GS2  104
#define NOTE_A2  110
#define NOTE_AS2  117
#define NOTE_B2  123
#define NOTE_C3  131
#define NOTE_CS3  139
#define NOTE_D3  147
#define NOTE_DS3  156
#define NOTE_E3  165
#define NOTE_F3  175
#define NOTE_FS3 185
#define NOTE_G3  196
#define NOTE_GS3  208
#define NOTE_A3  220
#define NOTE_AS3  233
#define NOTE_B3  247
#define NOTE_C4  262
#define NOTE_CS4  277
#define NOTE_D4  294
#define NOTE_DS4 311
#define NOTE_E4  330
#define NOTE_F4  349
#define NOTE_FS4  370
#define NOTE_G4  392
#define NOTE_GS4  415
#define NOTE_A4  440
#define NOTE_AS4  466
#define NOTE_B4  494
#define NOTE_C5  523
#define NOTE_CS5  554
#define NOTE_D5  587
#define NOTE_DS5  622
#define NOTE_E5  659
#define NOTE_F5  698
#define NOTE_FS5  740
#define NOTE_G5  784
#define NOTE_GS5  831
#define NOTE_A5  880
#define NOTE_AS5  932
#define NOTE_B5  988
#define NOTE_C6  1047
#define NOTE_CS6  1109
#define NOTE_D6  1175
#define NOTE_DS6  1245
#define NOTE_E6  1319
#define NOTE_F6  1397
#define NOTE_FS6  1480
#define NOTE_G6  1568
#define NOTE_GS6  1661
#define NOTE_A6  1760
#define NOTE_AS6  1865
#define NOTE_B6  1976
#define NOTE_C7  2093
#define NOTE_CS7  2217
#define NOTE_D7  2349
#define NOTE_DS7  2489
#define NOTE_E7  2637
#define NOTE_F7  2794
#define NOTE_FS7  2960
#define NOTE_G7  3136
#define NOTE_GS7  3322
#define NOTE_A7  3520
#define NOTE_AS7  3729
#define NOTE_B7  3951
#define NOTE_C8  4186
#define NOTE_CS8  4435
#define NOTE_D8  4699
#define NOTE_DS8  4978

setup.ino

// Setup
void setup() {

  // Setup Keyboard
  setupKeyboard();

  // Mozzi Start
  startMozzi( CONTROL_RATE );
  // Sets Attack and Decay Levels; assumes Sustain, Decay, and Idle times
  envelope1.setADLevels(200,200);
  // Sets Decay time in milliseconds
  envelope1.setDecayTime(100);
  // Sustain Time setting for envelope1
  envelope1.setSustainTime(32500);

}

——

People can contact us: https://www.donluc.com/?page_id=1927

Technology Experience

  • Single-Board Microcontrollers (PIC, Arduino, Raspberry Pi,Espressif, etc…)
  • IoT
  • Robotics
  • Camera and Video Capture Receiver Stationary, Wheel/Tank and Underwater Vehicle
  • Unmanned Vehicles Terrestrial and Marine
  • Research & Development (R & D)

Instructor and E-Mentor

  • IoT
  • PIC Microcontrollers
  • Arduino
  • Raspberry Pi
  • Espressif
  • Robotics

Follow Us

J. Luc Paquin – Curriculum Vitae – 2022 English & Español
https://www.jlpconsultants.com/luc/

Web: https://www.donluc.com/
Web: https://www.jlpconsultants.com/
Facebook: https://www.facebook.com/neosteam.labs.9/
YouTube: https://www.youtube.com/channel/UC5eRjrGn1CqkkGfZy0jxEdA
Twitter: https://twitter.com/labs_steam
Pinterest: https://www.pinterest.com/NeoSteamLabs/
Instagram: https://www.instagram.com/neosteamlabs/

Don Luc

Project #22: Synthesizer – Momentary Button – Mk09

——

#DonLucElectronics #DonLuc #Synthesizer #Mozzi #Keyboard #ADSREnvelope #Arduino #AdafruitMETROM0Express #Project #Fritzing #Programming #Electronics #Microcontrollers #Consultant

——

Momentary Button

——

Momentary Button

——

Momentary Button

——

Momentary Button – Panel Mount

It’s your basic black or blue action button. This is a very useful, small, panel-mount momentary switch. It is a SPST N.O. with the threaded portion being 6.75 mm in diameter. This button is perfect for basic On/Off functions. Overall length including leads and has small solder lugs for connection. These momentary buttons are rated up to 0.5A and 250VAC.

Momentary button connect two points in a circuit when you press them. Turns on and off a light emitting LED. When the button is open there is no connection between the two legs of the button, so the pin is connected to ground, through the pull-down resistor, and we read a LOW. When the button is closed, it makes a connection between its two legs, connecting the pin to 5 volts, so that we read a HIGH.

You can also wire this circuit the opposite way, with a pullup resistor keeping the input HIGH, and going LOW when the button is pressed. If so, the behavior of the sketch will be reversed, with the LED normally on and turning off when you press the button.

DL2208Mk02

1 x Adafruit METRO M0 Express
8 x Momentary Button – Panel Mount (Blue)
5 x Momentary Button – Panel Mount (Black)
13 x 10K Ohm Resistor
1 x LED Red 5mm
1 x SparkFun Cerberus USB Cable

Adafruit METRO M0 Express

KY0 – 0
KY1 – 1
KY2 – 2
KY3 – 3
KY4 – 4
KY5 – 5
KY6 – 6
KY7 – 7
KY8 – 8
LEDR – 9
KY10 – 10
KY11 – 11
KY12 – 12
KY13 – 13
VIN – +5V
GND – GND

——

DL2208Mk02p.ino

/* ***** Don Luc Electronics © *****
Software Version Information
Project #22: Synthesizer - Momentary Button - Mk09
22-09
DL2208Mk02p.ino
1 x Adafruit METRO M0 Express
8 x Momentary Button - Panel Mount (Blue)
5 x Momentary Button - Panel Mount (Black)
13 x 1K Ohm Resistor
1 x LED Red 5mm
1 x SparkFun Cerberus USB Cable
*/

// Include the Library Code


// Simple Keyboard
// Minimum reading of the button that generates a note
//const int iKeyboard0 = 0;
const int iKeyboard1 = 1;
const int iKeyboard2 = 2;
const int iKeyboard3 = 3;
const int iKeyboard4 = 4;
const int iKeyboard5 = 5;
const int iKeyboard6 = 6;
const int iKeyboard7 = 7;
const int iKeyboard8 = 8;
const int iKeyboard10 = 10;
const int iKeyboard11 = 11;
const int iKeyboard12 = 12;
const int iKeyboard13 = 13;
// Button is pressed
int iB0 = 1;
int iB1 = 1;
int iB2 = 1;
int iB3 = 1;
int iB4 = 1;
int iB5 = 1;
int iB6 = 1;
int iB7 = 1;
int iB8 = 1;
int iB10 = 1;
int iB11 = 1;
int iB12 = 1;
int iB13 = 1;

// The number of the LED Red pin 9
const int iLedR =  9;

// Software Version Information
String sver = "22-09";

void loop() {

  // isKeyboard
  isKeyboard();

}

getKeyboard.ino

// getKeyboard
// setupKeyboard
void setupKeyboard() {

  // Initialize the button pin as an input
//  pinMode(iKeyboard0, INPUT_PULLUP);
  pinMode(iKeyboard1, INPUT_PULLUP);
  pinMode(iKeyboard2, INPUT_PULLUP);
  pinMode(iKeyboard3, INPUT_PULLUP);
  pinMode(iKeyboard4, INPUT_PULLUP);
  pinMode(iKeyboard5, INPUT_PULLUP);
  pinMode(iKeyboard6, INPUT_PULLUP);
  pinMode(iKeyboard7, INPUT_PULLUP);
  pinMode(iKeyboard8, INPUT_PULLUP);
  pinMode(iKeyboard10, INPUT_PULLUP);
  pinMode(iKeyboard11, INPUT_PULLUP);
  pinMode(iKeyboard12, INPUT_PULLUP);
  pinMode(iKeyboard13, INPUT_PULLUP);

}
// isKeyboard
void isKeyboard() {

/*
  // Read the state of the button value 0
  if ( digitalRead(iKeyboard0) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 0
    iB0 = iB0 + 1;
    // Turn LED Red on
    digitalWrite(iLedR, HIGH );

  }
  else
  {

    iB0 = iB0 - 1;
    // Turn LED Red off
    digitalWrite(iLedR, LOW );

  }
*/
  // Read the state of the button value 1
  if ( digitalRead(iKeyboard1) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 1
    iB1 = iB1 + 1;
    // Turn LED Red on
    digitalWrite(iLedR, HIGH );

  }
  else
  {

    iB1 = iB1 - 1;
    // Turn LED Red off
    digitalWrite(iLedR, LOW );

  }

  // Read the state of the button value 2
  if ( digitalRead(iKeyboard2) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 2
    iB2 = iB2 + 1;
    // Turn LED Red on
    digitalWrite(iLedR, HIGH );

  }
  else
  {

    iB2 = iB2 - 1;
    // Turn LED Red off
    digitalWrite(iLedR, LOW );

  }

  // Read the state of the button value 3
  if ( digitalRead(iKeyboard3) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 3
    iB3 = iB3 + 1;
    // Turn LED Red on
    digitalWrite(iLedR, HIGH );

  }
  else
  {

    iB3 = iB3 - 1;
    // Turn LED Red off
    digitalWrite(iLedR, LOW );

  }

  // Read the state of the button value 4
  if ( digitalRead(iKeyboard4) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 4
    iB4 = iB4 + 1;
    // Turn LED Red on
    digitalWrite(iLedR, HIGH );

  }
  else
  {

    iB4 = iB4 - 1;
    // Turn LED Red off
    digitalWrite(iLedR, LOW );

  }

  // Read the state of the button value 5
  if ( digitalRead(iKeyboard5) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 5
    iB5 = iB5 + 1;
    // Turn LED Red on
    digitalWrite(iLedR, HIGH );

  }
  else
  {

    iB5 = iB5 - 1;
    // Turn LED Red off
    digitalWrite(iLedR, LOW );

  }

  // Read the state of the button value 6
  if ( digitalRead(iKeyboard6) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 6
    iB6 = iB6 + 1;
    // Turn LED Red on
    digitalWrite(iLedR, HIGH );

  }
  else
  {

    iB6 = iB6 - 1;
    // Turn LED Red off
    digitalWrite(iLedR, LOW );

  }

  // Read the state of the button value 7
  if ( digitalRead(iKeyboard7) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 7
    iB7 = iB7 + 1;
    // Turn LED Red on
    digitalWrite(iLedR, HIGH );

  }
  else
  {

    iB7 = iB7 - 1;// Turn LED Red off
    digitalWrite(iLedR, LOW );

  }

  // Read the state of the button value 8
  if ( digitalRead(iKeyboard8) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 8
    iB8 = iB8 + 1;
    // Turn LED Red on
    digitalWrite(iLedR, HIGH );

  }
  else
  {

    iB8 = iB8 - 1;
    // Turn LED Red off
    digitalWrite(iLedR, LOW );

  }

  // Read the state of the button value 10
  if ( digitalRead(iKeyboard10) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 10
    iB10 = iB10 + 1;
    // Turn LED Red on
    digitalWrite(iLedR, HIGH );

  }
  else
  {

    iB10 = iB10 - 1;
    // Turn LED Red off
    digitalWrite(iLedR, LOW );

  }

  // Read the state of the button value 11
  if ( digitalRead(iKeyboard11) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 11
    iB11 = iB11 + 1;
    // Turn LED Red on
    digitalWrite(iLedR, HIGH );

  }
  else
  {

    iB11 = iB11 - 1;
    // Turn LED Red off
    digitalWrite(iLedR, LOW );

  }

  // Read the state of the button value 12
  if ( digitalRead(iKeyboard12) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 12
    iB12 = iB12 + 1;
    // Turn LED Red on
    digitalWrite(iLedR, HIGH );

  }
  else
  {

    iB12 = iB12 - 1;
    // Turn LED Red off
    digitalWrite(iLedR, LOW );

  }

  // Read the state of the button value 13
  if ( digitalRead(iKeyboard13) == HIGH ) {

    // Button is pressed - pullup keeps pin high normally 13
    iB13 = iB13 + 1;
    // Turn LED Red on
    digitalWrite(iLedR, HIGH );

  }
  else
  {

    iB13 = iB13 - 1;
    // Turn LED Red off
    digitalWrite(iLedR, LOW );

  }

}

setup.ino

// Setup
void setup() {

  // Setup Keyboard
  setupKeyboard();

  // Initialize the LED Red pin 9 as an output
  pinMode(iLedR, OUTPUT);

}

——

People can contact us: https://www.donluc.com/?page_id=1927

Technology Experience

  • Single-Board Microcontrollers (PIC, Arduino, Raspberry Pi,Espressif, etc…)
  • IoT
  • Robotics
  • Camera and Video Capture Receiver Stationary, Wheel/Tank and Underwater Vehicle
  • Unmanned Vehicles Terrestrial and Marine
  • Research & Development (R & D)

Instructor and E-Mentor

  • IoT
  • PIC Microcontrollers
  • Arduino
  • Raspberry Pi
  • Espressif
  • Robotics

Follow Us

J. Luc Paquin – Curriculum Vitae – 2022 English & Español
https://www.jlpconsultants.com/luc/

Web: https://www.donluc.com/
Web: https://www.jlpconsultants.com/
Facebook: https://www.facebook.com/neosteam.labs.9/
YouTube: https://www.youtube.com/channel/UC5eRjrGn1CqkkGfZy0jxEdA
Twitter: https://twitter.com/labs_steam
Pinterest: https://www.pinterest.com/NeoSteamLabs/
Instagram: https://www.instagram.com/neosteamlabs/

Don Luc

Project #22: Synthesizer – Slide Linear Taper Pot – Mk08

——

#DonLucElectronics #DonLuc #Synthesizer #Mozzi #Keyboard #ADSREnvelope #Arduino #AdafruitMETROM0Express #Project #Fritzing #Programming #Electronics #Microcontrollers #Consultant

——

Slide Linear Taper Pot

——

Slide Linear Taper Pot

——

Slide Linear Taper Pot

——

10k Ohm Slide Linear Taper Pot – X-Large

A simple slide potentiometer can go a long way. Rated at 10k Ohm and 0.5W. Comes with solder tab connections. The taper profile for this slide:

Length: 80 cm
Width: 15 cm
Height: 12 cm

Slide Potentiometer Knob – X-Large

This is a simple knob that connects to the extra large sized linear slide potentiometer. Each knob uses friction to secure itself to fit onto the slide pot. Once attached, this small knob provides you with an easier to use potentiometer for your project.

Adafruit METRO M0 Express

Metro is our series of microcontroller boards for use with the Arduino IDE. This new Metro M0 Express board looks a whole lot like our original Metro 328, but with a huge upgrade. This Metro features a ATSAMD21G18 chip, an ARM Cortex M0+.

At the Metro M0’s heart is an ATSAMD21G18 ARM Cortex M0 processor, clocked at 48 MHz and at 3.3V logic. This chip has a 256K of FLASH and 32K of RAM. This chip comes with built in USB so it has USB-to-Serial program.

DL2208Mk01

1 x Adafruit METRO M0 Express
5 x 10k Ohm Slide Linear Taper Pot – X-Large
5 x Slide Potentiometer Knob – X-Large
1 x SparkFun Cerberus USB Cable

Adafruit METRO M0 Express

LP0 – Analog A0 – Blue
LP1 – Analog A1 – Green
LP2 – Analog A2 – Grey
LP3 – Analog A3 – Yellow
LP4 – Analog A4 – Purple
VIN – +5V
GND – GND

DL2208Mk01p.ino

/* ***** Don Luc Electronics © *****
Software Version Information
Project #22: Synthesizer - Slide Linear Taper Pot - Mk08
22-08
DL2208Mk01p.ino
1 x Adafruit METRO M0 Express
5 x 10k Ohm Slide Linear Taper Pot - X-Large
5 x Slide Potentiometer Knob - X-Large
1 x SparkFun Cerberus USB Cable
*/

// Include the Library Code

// Pot
int iPot0 = A0;
int iPot1 = A1;
int iPot2 = A2;
int iPot3 = A3;
int iPot4 = A4;
int sensorValue0 = 0;
int iValue0 = 0;
int sensorValue1 = 0;
int iValue1 = 0;
int sensorValue2 = 0;
int iValue2 = 0;
int sensorValue3 = 0;
int iValue3 = 0;
int sensorValue4 = 0;
int iValue4 = 0;

// Software Version Information
String sver = "22-08";

void loop() {

  // Pot
  isPot();

  // Delay in between reads
  delay( 1000 );

}

getPot.ino

// 10k Slide Linear Taper Pot - X-Large
// Pot
void isPot(){

  // Read the input on analog pin 0
  sensorValue0 = analogRead( iPot0 );
  iValue0 = map(sensorValue0, 0, 1023, 0, 255);
  Serial.print( "P0: " );
  Serial.print( iValue0 );
  // Read the input on analog pin 1
  sensorValue1 = analogRead( iPot1 );
  iValue1 = map(sensorValue1, 0, 1023, 0, 255);
  Serial.print( " P1: " );
  Serial.print( iValue1 );
  // Read the input on analog pin 2
  sensorValue2 = analogRead( iPot2 );
  iValue2 = map(sensorValue2, 0, 1023, 0, 255);
  Serial.print( " P2: " );
  Serial.print( iValue2 );
  // Read the input on analog pin 3
  sensorValue3 = analogRead( iPot3 );
  iValue3 = map(sensorValue3, 0, 1023, 0, 255);
  Serial.print( " P3: " );
  Serial.print( iValue3 );
  // Read the input on analog pin 4
  sensorValue4 = analogRead( iPot4 );
  iValue4 = map(sensorValue4, 0, 1023, 0, 255);
  Serial.print( " P4: " );
  Serial.println( iValue4 );

}

setup.ino

// Setup
void setup() {

  // Initialize serial communication at 9600 bits per second
  Serial.begin(9600);

}

——

People can contact us: https://www.donluc.com/?page_id=1927

Technology Experience

  • Single-Board Microcontrollers (PIC, Arduino, Raspberry Pi,Espressif, etc…)
  • IoT
  • Robotics
  • Camera and Video Capture Receiver Stationary, Wheel/Tank and Underwater Vehicle
  • Unmanned Vehicles Terrestrial and Marine
  • Research & Development (R & D)

Instructor and E-Mentor

  • IoT
  • PIC Microcontrollers
  • Arduino
  • Raspberry Pi
  • Espressif
  • Robotics

Follow Us

J. Luc Paquin – Curriculum Vitae – 2022 English & Español
https://www.jlpconsultants.com/luc/

Web: https://www.donluc.com/
Web: https://www.jlpconsultants.com/
Facebook: https://www.facebook.com/neosteam.labs.9/
YouTube: https://www.youtube.com/channel/UC5eRjrGn1CqkkGfZy0jxEdA
Twitter: https://twitter.com/labs_steam
Pinterest: https://www.pinterest.com/NeoSteamLabs/
Instagram: https://www.instagram.com/neosteamlabs/

Don Luc

Project #22: Synthesizer – Volume Sound – Mk07

——

DonLucElectronics #DonLuc #Synthesizer #UltrasonicSynth #Mozzi #Arduino #ArduinoProMini #Project #Fritzing #Programming #Electronics #Microcontrollers #Consultant

——

Volume Sound

——

Volume Sound

——

Volume Sound

——

Volume Sound

Volume the degree of loudness or the intensity of a sound. The volume of a sound is how loud or quiet the sound is. Sounds are vibrations that travel through the air. Volume, or loudness, is related to the strength, intensity, pressure, or power of the sound. Amplified vibrations result in louder sounds. There are a few ways of varying the volume.

I am using the Mozzi audio library to implement a simple synthesizer and using a potentiometer to control the amplitude of a sinewave with Mozzi sonification library. To convey the volume level. Volume it to an 8 bit range for efficient calculations.

DL2207Mk04

1 x Arduino Pro Mini 328 – 5V/16MHz
2 x HC-SR04 Ultrasonic Sensor
3 x 1M Ohm Potentiometer
3 x Knob
1 x Audio Jack 3.5mm
1 x SparkFun Audio Jack Breakout
1 x SparkFun USB Mini-B Breakout
1 x SPDT Slide Switch
1 x JST Jumper 2 Wire Connector
1 x JST Jumper 3 Wire Connector
1 x Insignia Speakers
1 x SparkFun Solderable Breadboard – Large
1 x SparkFun FTDI Basic Breakout – 5V
1 x SparkFun Cerberus USB Cable

Arduino Pro Mini 328 – 5V/16MHz

Ech – Digital 13
Tri – Digital 12
EcR – Digital 11
TrR – Digital 10
SPK – Digital 9
CAP – Analog A0
CAH – Analog A1
CAV – Analog A2
VIN – +5V
GND – GND

——

DL2207Mk04p.ino

/* ***** Don Luc Electronics © *****
Software Version Information
Project #22: Synthesizer - Volume - Mk07
22-07
DL2207Mk04p.ino
1 x Arduino Pro Mini 328 - 5V/16MHz
2 x HC-SR04 Ultrasonic Sensor
3 x 1M Ohm Potentiometer
3 x Knob
1 x Audio Jack 3.5mm
1 x SparkFun Audio Jack Breakout
1 x SparkFun USB Mini-B Breakout
1 x SPDT Slide Switch
1 x JST Jumper 2 Wire Connector
1 x JST Jumper 3 Wire Connector
1 x Insignia Speakers
1 x SparkFun Solderable Breadboard - Large
1 x SparkFun FTDI Basic Breakout - 5V
1 x SparkFun Cerberus USB Cable
*/

// Include the Library Code
// Mozzi
#include <MozziGuts.h>
// Oscillator
#include <Oscil.h>
// Table for Oscils to play
#include <tables/cos2048_int8.h>
// Smoothing Control
#include <Smooth.h>
// Maps unpredictable inputs to a range
#include <AutoMap.h>

// Desired carrier frequency max and min, for AutoMap
const int MIN_CARRIER_FREQ = 22;
const int MAX_CARRIER_FREQ = 440;

// Desired intensity max and min, for AutoMap, note they're inverted for reverse dynamics
const int MIN_INTENSITY = 700;
const int MAX_INTENSITY = 10;

// Desired mod speed max and min, for AutoMap, note they're inverted for reverse dynamics
const int MIN_MOD_SPEED = 10000;
const int MAX_MOD_SPEED = 1;

// Maps unpredictable inputs to a range
AutoMap kMapCarrierFreq(0,1023,MIN_CARRIER_FREQ,MAX_CARRIER_FREQ);
AutoMap kMapIntensity(0,1023,MIN_INTENSITY,MAX_INTENSITY);
AutoMap kMapModSpeed(0,1023,MIN_MOD_SPEED,MAX_MOD_SPEED);

// Set the input for the knob to analog pin 0
const int KNOB_PIN = A0;
// Set the analog input for fm_intensity
int LDR1_PIN;
// Set the analog input for mod rate
int LDR2_PIN;

// Table for Oscils to play
Oscil<COS2048_NUM_CELLS, AUDIO_RATE> aCarrier(COS2048_DATA);
Oscil<COS2048_NUM_CELLS, AUDIO_RATE> aModulator(COS2048_DATA);
Oscil<COS2048_NUM_CELLS, CONTROL_RATE> kIntensityMod(COS2048_DATA);

// Harmonics (Brightness)
int iModRatio = A1;
int mod_ratio;
// Carries control info from updateControl to updateAudio
long fm_intensity;

// Smoothing for intensity to remove clicks on transitions
float smoothness = 0.95f;
Smooth <long> aSmoothIntensity(smoothness);

// Trigger pin 12 to pitch distance sensor
const int iTrigPitch = 12;
// Echo Receive pin 13 to pitch distance sensor
const int iEchoPitch = 13;
// Define the useable range of the pitch sensor
const int pitchLowThreshold = 45;
const int pitchHighThreshold = 2;
// Stores the distance measured by the distance sensor
float distance = 0;
// Trigger pin 10 to rate distance sensor
const int iTrigRate = 10;
// Echo Receive pin 13 to pitch distance sensor
const int iEchoRate = 11;
// Define the useable range of the pitch sensor
const int rateLowThreshold = 45;
const int rateHighThreshold = 2;
// Stores the distance measured by the distance sensor
float rate = 0;

// Volume
// Set the input for the knob to analog pin 2
const int iVolKnob = A2;
// To convey the Volume level from updateControl() to updateAudio()
byte bVolume;

// Mini Speaker
int SPK = 9;

// Software Version Information
String sver = "22-07";

void loop() {

  // Audio Hook
  audioHook();

}

getHC-SR04.ino

// HC-SR04 Ultrasonic Sensor
// Setup HC-SR04
void setupHCSR04() {

  // The trigger iTrig Pitch will output pulses of electricity
  pinMode(iTrigPitch, OUTPUT);
  // The echo iEcho will measure the duration of pulses coming back from the distance sensor
  pinMode(iEchoPitch, INPUT);

  // The trigger iTrig Rate will output pulses of electricity
  pinMode(iTrigRate, OUTPUT);
  // The echo iEcho will measure the duration of pulses coming back from the distance sensor
  pinMode(iEchoRate, INPUT);

}
// Distance
float isDistance() {

  // Variable to store the time it takes for a ping to bounce off an object
  float echoTime;
  // Variable to store the distance calculated from the echo time
  float calculatedDistance;

  // Send out an ultrasonic pulse that's 10ms long
  digitalWrite(iTrigPitch, HIGH);
  delayMicroseconds(10);
  digitalWrite(iTrigPitch, LOW);

  // Use the pulseIn command to see how long it takes for the
  // pulse to bounce back to the sensor
  echoTime = pulseIn(iEchoPitch, HIGH);

  // Calculate the distance of the object that reflected the pulse
  // (half the bounce time multiplied by the speed of sound)
  calculatedDistance = echoTime * 0.034 / 2;

  // Send back the distance that was calculated
  return calculatedDistance;

}
// Rate
float isRate() {

  // Variable to store the time it takes for a ping to bounce off an object
  float echoTime;
  // Variable to store the distance calculated from the echo time
  float calculatedDistance;

  // Send out an ultrasonic pulse that's 10ms long
  digitalWrite(iTrigRate, HIGH);
  delayMicroseconds(10);
  digitalWrite(iTrigRate, LOW);

  // Use the pulseIn command to see how long it takes for the
  // pulse to bounce back to the sensor
  echoTime = pulseIn(iEchoRate, HIGH);

  // Calculate the distance of the object that reflected the pulse
  // (half the bounce time multiplied by the speed of sound)
  // cm = 58.0
  calculatedDistance = echoTime * 0.034 / 2;

  // Send back the distance that was calculated
  return calculatedDistance;

}

getMozzi.ino

// Mozzi
// Update Control
void updateControl(){

  // Variable to store the distance measured by the sensor
  distance = isDistance();
  // Low Threshold
  if ( distance >= pitchLowThreshold) {

    // pitchLowThreshold
    distance = pitchLowThreshold;

  }
  // High Threshold
  if ( distance < pitchHighThreshold){

    // pitchHighThreshold
    distance = pitchHighThreshold;

  }

  // Variable to store the distance measured by the sensor
  rate = isRate();
  // Low Threshold
  if ( rate >= rateLowThreshold) {

    // rateLowThreshold
    rate = rateLowThreshold;

  }
  // High Threshold
  if ( rate < rateHighThreshold){

    // rateHighThreshold
    rate = rateHighThreshold;

  }

  // Map
  distance = map(distance, 45, 2, 0, 1023);
  rate = map(rate, 45, 2, 0, 1023);

  // Read the knob
  // Value is 0-1023
  int knob_value = mozziAnalogRead(KNOB_PIN);

  // Read the mod_ratio
  // Value is 0-1023
  mod_ratio = mozziAnalogRead(iModRatio);

  // Map
  mod_ratio = map(mod_ratio, 0, 1023, 2, 15);

  // Map the knob to carrier frequency
  int carrier_freq = kMapCarrierFreq(knob_value);

  // Calculate the modulation frequency to stay in ratio
  int mod_freq = carrier_freq * mod_ratio;

  // Set the FM oscillator frequencies
  aCarrier.setFreq(carrier_freq);
  aModulator.setFreq(mod_freq);

  // Read the light dependent resistor on the width
  LDR1_PIN = distance;
  int LDR1_value = LDR1_PIN;

  int LDR1_calibrated = kMapIntensity(LDR1_value);

  // Calculate the fm_intensity
  // Shift back to range after 8 bit multiply
  fm_intensity = ((long)LDR1_calibrated * (kIntensityMod.next()+128))>>8;

  // Read the light dependent resistor on the speed
  LDR2_PIN = rate;
  int LDR2_value= LDR2_PIN;

  // Use a float here for low frequencies
  float mod_speed = (float)kMapModSpeed(LDR2_value)/1000;

  kIntensityMod.setFreq(mod_speed);

  // Read the variable resistor for volume
  // Value is 0-1023
  int iVolValue = mozziAnalogRead(iVolKnob);
  // map it to an 8 bit range for efficient calculations in updateAudio
  bVolume = map(iVolValue, 0, 1023, 155, 1);

}
// Update Audio
int updateAudio()
{

  // Update Audio
  long modulation = aSmoothIntensity.next(fm_intensity) * aModulator.next() * bVolume;
  return aCarrier.phMod(modulation);

}

setup.ino

// Setup
void setup() {

  // Setup HC-SR04
  setupHCSR04();

  // Delay
  delay( 200 );

  // Mozzi Start
  startMozzi();

}

——

People can contact us: https://www.donluc.com/?page_id=1927

Technology Experience

  • Single-Board Microcontrollers (PIC, Arduino, Raspberry Pi,Espressif, etc…)
  • IoT
  • Robotics
  • Camera and Video Capture Receiver Stationary, Wheel/Tank and Underwater Vehicle
  • Unmanned Vehicles Terrestrial and Marine
  • Research & Development (R & D)

Instructor and E-Mentor

  • IoT
  • PIC Microcontrollers
  • Arduino
  • Raspberry Pi
  • Espressif
  • Robotics

Follow Us

J. Luc Paquin – Curriculum Vitae – 2022 English & Español
https://www.jlpconsultants.com/luc/

Web: https://www.donluc.com/
Web: https://www.jlpconsultants.com/
Facebook: https://www.facebook.com/neosteam.labs.9/
YouTube: https://www.youtube.com/channel/UC5eRjrGn1CqkkGfZy0jxEdA
Twitter: https://twitter.com/labs_steam
Pinterest: https://www.pinterest.com/NeoSteamLabs/
Instagram: https://www.instagram.com/neosteamlabs/

Don Luc

Microcontrollers Instructor Or Kit Or Consultant

——

#DonLucElectronics #DonLuc #Project #Fritzing #Programming #Electronics #Microcontrollers #Consultant

——

2012

Microcontrollers Instructor Or Kit Or Consultant

——

Microcontrollers Instructor Or Kit Or Consultant

——

Microcontrollers Instructor Or Kit Or Consultant

——

Microcontrollers Instructor Or Kit Or Consultant

I am a highly skilled with over 45 years of experience in various industries. I know that I am considered as a dinosaur in this business where you are considered old when you hit 25, but there are some of us old fogies at over twice that, that are still active and can still provide a full contribution to this or these fields.

Instructor: Computer and Electronic and Microcontrollers and Prototyping Platform

Microcontrollers

Each of these kits have similar but slightly different accessories that should hopefully get you up and running as fast and easy as possible. These beginner-friendly microcontrollers are easy to use and program with just a computers or laptop, a USB cable, and some open-source software. All the projects, here we come. Whether you are looking to build some electronic projects, learn programming, or wanting to teach others about electronics, this tutorial will help you figure out what microcontroller is right for your needs, goals, and budgets. Here is some helpful content to start you on your electronics journey.

Project Microcontrollers Instructor

A project is a sequence of related tasks and activities that help you create something new or change an existing product microcontrollers (2012 – 2022).

Custom Kit Elaborate

Create the exact kit you need. Tell us the components you need, or we can collaborate with you to define parts needed and elaborate a customer experience based on your idea.

Microcontrollers

The project will first be assembled on a breadboard. If there is enough demand either a PCB, or a kit BOM, or a kit BOM soldered version, or kit BOM enclosures, or a kit BOM soldered version enclosures, and sold here.

BOM (Bill Of Material)

  • PCB
  • Microcontrollers
  • Bluetooth
  • WiFi
  • E-Textiles
  • Audio
  • Buttons
  • Switches
  • Capacitors
  • Potentiometer
  • Resistors
  • Connectors
  • LED
  • Cables
  • Display
  • RTC
  • Micro SD card
  • Biometrics Sensor
  • Capacitive Sensor
  • Distance Sensor
  • Environment Sensor
  • Flex Sensor
  • Force Sensor
  • Imaging Sensor
  • Infrared Sensor
  • Movement Sensor
  • Radiation Sensor
  • RFID Sensor
  • Robotics
  • Wireless
  • Mesh Network
  • GPS Receiver
  • Battery
  • Antennas
  • Etc…

PCB

  • PCB Perfboard
  • PCB Breadboard
  • PCB Etching Solution
  • PCB CNC Router
  • PCB Manufacturing

Enclosures

  • Wood
  • Plywood
  • Particle Boards
  • MDF
  • Acrylic
  • Plastic Enclosures
  • Diecast Enclosures
  • Extruded Enclosures
  • Chassis
  • 3D Printing
  • Etc…

Contact

People can contact us: https://www.donluc.com/?page_id=1927

Technology Experience

  • Single-Board Microcontrollers (PIC, Arduino, Raspberry Pi,Espressif, etc…)
  • IoT
  • Robotics
  • Camera and Video Capture Receiver Stationary, Wheel/Tank and Underwater Vehicle
  • Unmanned Vehicles Terrestrial and Marine
  • Research & Development (R & D)

Instructor and E-Mentor

  • IoT
  • PIC Microcontrollers
  • Arduino
  • Raspberry Pi
  • Espressif
  • Robotics

Follow Us

J. Luc Paquin – Curriculum Vitae – 2022 English & Español
https://www.jlpconsultants.com/luc/

Web: https://www.donluc.com/
Web: https://www.jlpconsultants.com/
Facebook: https://www.facebook.com/neosteam.labs.9/
YouTube: https://www.youtube.com/channel/UC5eRjrGn1CqkkGfZy0jxEdA
Twitter: https://twitter.com/labs_steam
Pinterest: https://www.pinterest.com/NeoSteamLabs/
Instagram: https://www.instagram.com/neosteamlabs/

Don Luc
