Project #2 – Lens – LED – Mk4

by

LensLEDMk4

1 X Panel Mount 10K potentiometer (Breadboard Friendly) – 10K Linear

3 X Jumper Wires Premium 6″ M/M

1 X Project #2 – Lens – LED – Mk3

LensLEDMk4.3.ino

// ***** Don Luc *****
// Software Version Information
// 4.1 - 4.2 - 4.3
// sensorNumber

#include
// Which pin on the Arduino is connected to the NeoPixels?
#define PIN 6
// How many NeoPixels are attached to the Arduino?
#define NUMPIXELS 2
Adafruit_NeoPixel pixels = Adafruit_NeoPixel(NUMPIXELS, PIN, NEO_GRB + NEO_KHZ800);
// Panel Mount 1K potentiometer Brightneed
const int sensorPin = A0;
// Panel Mount 1K potentiometer
const int sensorDelay = A1;
// Panel Mount 1K potentiometer
const int sensorNumber = A2;
// variables:
int sensorValue = 0;         // the sensor value
int sensorMin = 1023;        // minimum sensor value
int sensorMax = 0;           // maximum sensor value
int red = 0;
int green = 0;
int blue = 0;
int x = 0;
long delayVal = 0;
long xp = 0;
int y = 0;
int z = 0;

void loop() {

  z = analogRead(sensorNumber);
  y = (z / 127);

  // range value:
  switch (y) {
    case  0:
      // Blue
      red = 0;
      green = 102;
      blue = 204;
      neopix();
      break;
    case 1:
      // Yellow
      red = 255;
      green = 255;
      blue = 0;
      neopix();
      break;
    case 2:
      // Pink
      red = 255;
      green = 153;
      blue = 203;
      neopix();
      break;
    case 3:
      // White
      red = 255;
      green = 255;
      blue = 255;
      neopix();
      break;
    case 4:
      // Green
      red = 0;
      green = 255;
      blue = 0;
      neopix();
      break;
    case 5:
      // Orange
      red = 255;
      green = 102;
      blue = 0;
      neopix();
      break;
    case 6:
      // Violet
      red = 204;
      green = 102;
      blue = 204;
      neopix();
      break;
    case 7:
        xp = analogRead(sensorDelay);
        delayVal = (1000 * xp);
        // range value:
        switch (x) {
          case 0:
            // Blue
            red = 0;
            green = 102;
            blue = 204;
            neopix();
            delay(delayVal); // Delay for a period of time (in milliseconds).
            x = 1;
            break;
          case 1:
            // Yellow
            red = 255;
            green = 255;
            blue = 0;
            neopix();
            delay(delayVal); // Delay for a period of time (in milliseconds).
            x = 2;
            break;
          case 2:
            // Pink
            red = 255;
            green = 153;
            blue = 203;
            neopix();
            delay(delayVal); // Delay for a period of time (in milliseconds).
            x = 3;
            break;
          case 3:
            // White
            red = 255;
            green = 255;
            blue = 255;
            neopix();
            delay(delayVal); // Delay for a period of time (in milliseconds).
            x = 4;
            break;
          case 4:
            // Green
            red = 0;
            green = 255;
            blue = 0;
            neopix();
            delay(delayVal); // Delay for a period of time (in milliseconds).
            x = 5;
            break;
          case 5:
            // Orange
            red = 255;
            green = 102;
            blue = 0;
            neopix();
            delay(delayVal); // Delay for a period of time (in milliseconds).
            x = 6;
            break;
          case 6:
            // Violet
            red = 204;
            green = 102;
            blue = 204;
            neopix();
            delay(delayVal); // Delay for a period of time (in milliseconds).
            x = 0;
            break;
          }
          break;
  }

}

neopin.ino

void neopix() {

  for(int i=0; i<NUMPIXELS; i++){

     // read the sensor:
    sensorValue = analogRead(sensorPin);

    // apply the calibration to the sensor reading
    sensorValue = map(sensorValue, sensorMin, sensorMax, 0, 255);

    // in case the sensor value is outside the range seen during calibration
    sensorValue = constrain(sensorValue, 0, 255);

    // pixels.Color takes RGB values, from 0,0,0 up to 255,255,255
    pixels.setBrightness( sensorValue );
    pixels.setPixelColor(i, pixels.Color(red,green,blue));
    pixels.show(); // This sends the updated pixel color to the hardware.

    delay(50); // Delay for a period of time (in milliseconds).

  }

}

setup.ino

void setup() {
  pixels.begin(); // This initializes the NeoPixel library.
}

Don Luc

Project #2 – Lens – LED – Mk3

by

neopixMk3

1 X Arduino and Breadboard Holder

1 X Breadboard – Translucent Self-Adhesive (Clear)

1 X Arduino UNO Rev3

2 X Panel Mount 10K potentiometer (Breadboard Friendly) – 10K Linear

13 X Jumper Wires Premium 6″ M/M

1 X Cable

1 X Project #2 – Lens – LED – Mk1

LensLEDMk3.3.ino

// ***** Don Luc *****
// Software Version Information
// 3.0
// Real
// 3.1
// sensorValue
// 3.2
// red, green, blue
// 3.3
// delayVal

#include <Adafruit_NeoPixel.h>
// Which pin on the Arduino is connected to the NeoPixels?
#define PIN 6
// How many NeoPixels are attached to the Arduino?
#define NUMPIXELS 2
Adafruit_NeoPixel pixels = Adafruit_NeoPixel(NUMPIXELS, PIN, NEO_GRB + NEO_KHZ800);
// Panel Mount 1K potentiometer Brightneed
const int sensorPin = A0;
// Panel Mount 1K potentiometer
const int sensorDelay = A1;
// variables:
int sensorValue = 0;         // the sensor value
int sensorMin = 1023;        // minimum sensor value
int sensorMax = 0;           // maximum sensor value
int red = 0;
int green = 0;
int blue = 0;
int x = 0;
long delayVal = 0;
long xp = 0;

void loop() {

  xp = analogRead(sensorDelay);
  delayVal = (20000 + xp);
  // range value:
  switch (x) {
    case 0:
      // Blue
      red = 0;
      green = 102;
      blue = 204;
      neopix();
      delay(delayVal); // Delay for a period of time (in milliseconds).
      x = 1;
      break;
    case 1:
      // Yellow
      red = 255;
      green = 255;
      blue = 0;
      neopix();
      delay(delayVal); // Delay for a period of time (in milliseconds).
      x = 2;
      break;
    case 2:
      // Pink
      red = 255;
      green = 153;
      blue = 203;
      neopix();
      delay(delayVal); // Delay for a period of time (in milliseconds).
      x = 3;
      break;
    case 3:
      // White
      red = 255;
      green = 255;
      blue = 255;
      neopix();
      delay(delayVal); // Delay for a period of time (in milliseconds).
      x = 4;
      break;
    case 4:
      // Green
      red = 0;
      green = 255;
      blue = 0;
      neopix();
      delay(delayVal); // Delay for a period of time (in milliseconds).
      x = 5;
      break;
    case 5:
      // Orange
      red = 255;
      green = 102;
      blue = 0;
      neopix();
      delay(delayVal); // Delay for a period of time (in milliseconds).
      x = 6;
      break;
    case 6:
      // Violet
      red = 204;
      green = 102;
      blue = 204;
      neopix();
      delay(delayVal); // Delay for a period of time (in milliseconds).
      x = 0;
      break;
  }

}

neopin.ino

void neopix() {

  for(int i=0; i

setup.ino


void setup() {
  pixels.begin(); // This initializes the NeoPixel library.
}



Don Luc

Project #2 – Lens – LED – Mk2

by

LensLEDMk2

1 X Arduino UNO Rev3

1 X Cable

1 X Project #2 – Lens – LED – Mk1

LensLEDMk2.1.ino

// ***** Don Luc *****
// Software Version Information
// 2.1

#include <Adafruit_NeoPixel.h>

// Which pin on the Arduino is connected to the NeoPixels?
#define PIN            6

// How many NeoPixels are attached to the Arduino?
#define NUMPIXELS      2

Adafruit_NeoPixel pixels = Adafruit_NeoPixel(NUMPIXELS, PIN, NEO_GRB + NEO_KHZ800);

int delayval = 500; // delay for half a second

void loop() {

  for(int i=0;i<NUMPIXELS;i++){
    // pixels.Color takes RGB values, from 0,0,0 up to 255,255,255
    pixels.setBrightness(125);
    pixels.setPixelColor(i, pixels.Color(50,150,50)); // Moderately bright green color.
    pixels.show(); // This sends the updated pixel color to the hardware.
    delay(delayval); // Delay for a period of time (in milliseconds).

  }
}

setup.ino

void setup() {
  pixels.begin(); // This initializes the NeoPixel library.
}

Don Luc

Project #1 – The AcceleroSynth – Mk1

by

Apr 3, 2012 @ 15:03


We are finally ready for our first electronics project, The AcceleroSynth. It is an microcontroller-based (Arduino) music synth that is controller by a 3 axis analog accelerometer. It will be both a hardware and a software synth. This is the announcement for the project and in the coming days I will post the BOM (Bill of Material), schematics and Arduino code with the first assembly video. The project will first be assembled on a protoboard, then a soldered version will be built either on a perfboard or on an Arduino ProtoShield. If there is enough demand either a PCB or an Arduino Shield will be built for the project and sold here. More on that later. The first installment on the building of the project should be up on a few days.

Don Luc

Tomorrow’s Video – An Introduction to Microcontrollers

by

Mar 28, 2012 @ 22:12

I’m hard at work… Actually make that “I think” that tomorrow’s video post will be an introduction to microcontrollers. I will dig some stuff out of the drawers tomorrow and as usual make it up as I go and it will probably be about microcontrollers.

Sleep tight…

Don Luc

New Format and Name

by

Mar 14, 2012 @ 23:39

This blog was launched close to 2 years ago and was active only a few weeks. Our work load got the best of us and most of the blogs we maintained have been inactive since then. In the past weeks we have started to revamp our web presence and for this blog the first step was to change its focus and name. It was started as a consulting industry blog called “Consult Ants” and it will now become “The Alpha Geek” a video blog about all things technological. In the coming days the first video post will be live and we will also start posting project from programming of all kind (desktop, microcontroller, web and mobile) to electronics and even music instrument hacks.

Watch this space in the coming days for our debut video and further announcements.
